WIRING DEVICES
mkelectric.co.ukEdge
TM
Technical: General information
Mounting Boxes
Due to the slimline design MK Edge accessories
require deeper back boxes than standard. They
are designed to fit into folded metal boxes that
comply with BS 4662. To ensure products can
be correctly installed, the box must always be
installed flush or sub flush to the surface to a
maximum depth of 6mm.
The recommended depth of boxes for the
different types of wiring accessories are as
follows:
MOUNTING BOXES
Product
Box Depth
Socket Outlets
35mm
Lockable Socket
47mm
Lockable Switch
47mm
German style 2 pole + E
Socket Outlet mounted in
Euro Frame
47mm
Connection Units
47mm
Plateswitches
35mm
Grid System Switches*
35mm
Dimmer Switches
35mm
Telephone, Television and
Data Outlets
35mm
Cooker Control and 50A
Switches
47mm
Shaver Supply Units
47mm
32A Triple Pole and Neutral
Switch
List no. 5268ALM
*Note: If Grid system accessories are to be fitted and
the installation requires the attachment of conduit via
nuts inside the mounting box, then it is recommended
that a box depth of 47mm is used.
Fixing Screws
The surface head of Edge fixing screws is
treated and compliment the finish of the
frontplate. To prevent damage to the fixing screw
extreme care is required. It is recommended that
a screwdriver with a maximum blade of 3.5mm
is used.
Wiring Devices Technical
– Edge™
