Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

80 / 140

20/76 CI insulated enclosures
Modular busbar system
2010 CA08103002Z-EN
Modularbusbar system
Clearance between busbar supports
with transport split, busbar coupling kits
For fitting a busbar support outside the knockouts, 2 × HSH-CI or 2 × HSH0632 are required. Exception: For SH0632 only 1 × HSH0632 is required.
Busbar support Busbar system Additional support bracket
for busbar support
Clearance between busbar
support
Terminal
L1, L2, L3 N, PE, PEN
mm
SH0165/2 160 A, 5 pole HSH0632 125 K12X5-1 K12X5-1
SH0635/3 250 A, 5 pole HSH-CI 175 K20X5 K20X5
400 A, 5 pole HSH-CI 175 K20X10 K20X5
630 A, 3 pole HSH-CI 125 K20X10 -
SH0635/4 250 A, 5 pole HSH-CI 125 K20X5 K20X5
400 A, 5 pole HSH-CI 125 K20X10 K20X5
630 A, 5 pole HSH-CI 125 K20X10 K20X10
SH1005/4 1000A, 5 pole HSH-CI 125 AVS30L AVS30PEN
SH1603/4 1600A, 3 pole HSH-CI 125 AVS40 -
SH0632 HSH0632 ~170 - K12X5, K20X5
CI…, SKA...
