19/74 Circuit-breakers, fuses
Auxiliary contacts for FAZ-NA, FAZ-RT
2010 CA08103002Z-EN
Auxiliarycontacts for FAZ-NA, FAZ-RT
Z-NHK Z-IHK-NA
Electrical
Standards IEC/EN 60947-5-1,
IEC/EN 62019
IEC/EN 60947-5-1,
IEC/EN 62019
Rated voltage V AC 230 250
Contact function 2 C 1 N/O + 1 NC
Rated frequency f Hz 50/60 50/60
Rated operational current Ie A 2 6
Thermal rated operational current Ith A 2 6
Rated operational current
AC-13 Ie A 3 (250 V AC) 3 (250 V AC)
AC-15 Ie A 2 (250 V AC) 2 (250 V AC)
DC-12 Ie A 0.5 (110 V DC) 0.5 (110 V DC)
Rated insulation voltage Ui V AC 250 250
Minimum operating voltage per contact Umin V DC 5 5
Minimum operating current Imin mA 10 (DC) 10 (AC/DC)
Rated impulse withstand voltage
(1.2/ 50 m)
Uimp kV 2.5 4
Rated conditional short-circuit current
with 6 A back-up fuse
Ik kA 1 1
Max. admissible back-up fuse A gL 6
Mechanical
Standard front dimension mm 45 45
Device height mm 80 80
Mounting width mm 8.8 (0.5 SU) 8.8 (0.5 SU)
Mounting For fitting to to left side of
FAZ-...-NA, FAZ-...-RT, FAZ-XAA-NA...
-
Protection type
Enclosed IP40 IP40
Terminal protection Busbar tag shroud to BGV A3 Busbar tag shroud to BGV A3
Terminals Lift terminals Lift terminals
Terminal capacity
AWG 20 - 14 -
mm 2 0.5 - 2.5
Terminal screws M3 (Pozidriv Z0) M3 (Pozidriv Z0)
Tightening torque of the terminal screws Nm - ≦ 1.2
FAZ-XAA-NA12-110VAC FAZ-XAA-NA110-415VAC
Electrical
Voltage range V AC 12 - 110 110 - 415
V DC 12 - 60 110 - 230
Rated frequency f Hz 50/60 50/60
Mechanical
Standard front dimension mm 45 45
Device height mm 105 105
Mounting width mm 17.5 17.5
Mounting Quick attachment with two
engagement positions for top-hat rail
to EN 50022
Quick attachment with two
engagement positions for top-hat rail
to EN 50022
Protection type
Enclosed IP40 IP40
Terminal protection Busbar tag shroud to BGV A3 Busbar tag shroud to BGV A3
Terminals top and bottom Twin-purpose terminals Twin-purpose terminals
Terminal capacity
Solid AWG 18 - 10 18 - 10
Two-wire AWG 18 - 10 18 - 10
Z-NHK, Z-IHK-NA, FAZ-XAA-NA...
