Power meter
2010 CA08103002Z-EN
Powermeter
KWZ-3PH KWZ-3PH-65
Electrical
Rated operating voltage Ue V AC 230 - 240/400-415
Voltage range V AC 110 - 254/190-440
Rated operational current Ie A 1, 5 10
Max. current Imax A 6 63
Rated frequency f Hz 50, 60
Limiting frequency Hz 47 - 63
Own consumption per phase (current path) VA ≦ 0.5 (each phase) ≦ 4 (each phase)
Overload, short-term 20 x Imax. / 0.5 s 30 x Imax. / 10 ms
Auxilliary voltage From measurement
Input signal Sine-shaped
Accuracy class 1
LED signal 1 pulse / 0.1 Wh 1 pulse / Wh
Pulse output
Rated value Max. 110 V AC/DC, 50 mA
Switching contact (potential-free) Optocoupler
Pulse value (selectable) 1 pulse / 10 Wh, 100 Wh,
1 kWh, 10 kWh
optional 1Imp. / 10 VArh, 100 VArh,
1 kVArh, 10 kVArh
1 pulse / 1 Wh, 10 - 100 Wh,
1 kWh, 10 kWh
optional 1Imp. / 10 VArh, 100 VArh,
1 kVArh, 10 kVArh
Pulse duration (selectable) ms 50, 100, 150, 200, 300, 400, 500
Programmable parameters Network types (single-phase,
3-phase, 3- or 4-conductor),
External current and voltage transformers,
mean performance, pulse output
Network types (3-phase,
3- or 4-conductor),
Partial energy and double tariff, mean perfor-
mance, pulse output
Overvoltage category III
Insulation voltage (phase - phase) V 450 300
Rated impulse withstand voltage
(1.2/50) ms
kV 5
Test voltage
Input/pulse output kV 2.75
All circuits and ground kV 4
Protection class II
Mechanical
Standard front dimension mm 45
Device height mm 89
Mounting width mm 71.2
Weight g 260
Display LCD 8 digit
Digit height mm 6
Maximum display Adjustable 999999.99 kWh
Resolution Adjustable 10 W
Measurement display arranged into 6 pages arranged into 7 pages
Mounting Quick attachment for top-hat rail IEC/EN 60715
Protection type device front/
terminals
IP52/IP20
Terminals top and bottom Screw terminals
Terminal capacities
Current connections
Solid mm 2 0.05 - 4 1 - 10
Stranded mm 2 0.05 - 2.5 1 - 13
Voltage connections
Solid mm 2 0.05 - 4 1 - 4
Stranded mm 2 0.05 - 2.5 1 - 3
Admissible relative humidity Also suitable for tropical conditions
Reference temperature °C 23 ± 2
Temperature range °C -5 - +55
Storage and transportation temperature range °C -25 - +70
Pollution degree 2
KWZ-3PH
