Fuse material
2010 CA08103002Z-EN
www.eaton.comFusematerial
D01-S0/
D02-S0/
Electrical
Number of poles
1P
3P
1P
3P
Rated operating voltage
V AC
400
400
V DC
250
250
Rated conditional short-circuit current tested with links
I
e
kA
50 (AC) / 8 (DC)
50 (AC) / 8 (DC)
Rated frequency
f
Hz
-
-
Rated operational current
I
e
A
16
63
Conventional thermal current
with fuse links
I
th
A
-
-
Rated operating mode
-
-
Overvoltage category
-
-
Utilization category
-
-
Rated impulse withstand voltage
U
imp
kV
-
-
Current heat loss per contact at I
e
W -
-
Heat dissipation
Heat dissipation per contact with fuse link at I
e
W -
-
Max. permissible heat dissipation of the
fuse links
W -
-
Utilization category
gG (gL)
gG (gL)
Mechanical
Standard front dimension
mm 45
45
Device height
mm 68
68
Mounting width
mm 27 (per pole)
27 (per pole)
Weight
g
1P 76
3P 230
1P 76
3P 230
Electrical thread
E14
E18
Mounting
Quick attachment for top-hat rail
IEC/EN 60715
Protection type
Enclosed
-
-
Terminals
Double function terminals
Terminal capacity
Solid
mm
2
1.5 - 35
1.5 - 35
Temperature range
°C
-
-
Terminal screw tightening torque
Nm 2.5 - 3
2.5 - 3
Pollution degree
-
-
Track resistance
CTI 200
CTI 200
Z-DII./SE
Electrical
Standards
DIN EN 60269-1 (VDE 0636 part 10), DIN EN 60269-3 (VDE 0636 part 30),
DIN VDE 0636-301, CEE 16, IEC/EN 60269-1, IEC/EN 60269-3
Utilization category
gG (gL), DZ
Rated voltage
AC
U
n
V
500
DC
U
n
V
400
Rated frequency
f
Hz
45 - 65
Insulation class
C-VDE0110
Rated short-circuit breaking capacity at 1.1 x U
n
AC
kA
50/cosϕ
= 0.2
DC
kA
8/τ = 15 ms
D01-S, D02-S..., Z-DII-/SE
