Auxiliarycontacts, shunt releases
AZ-XHI11
AZ-XAA
FI-XHI11
F
100 A
FIPA-XAM011
125 A FI and Type B
Electrical
Contact function
1 N/O + 1 NC
-
1 N/O + 1 NC
1 C/O + 1 NC
Voltage range
V AC
-
12 - 110
110 - 415
-
-
Voltage range
V DC
-
12 - 60
110 - 220
-
-
Min. operating voltage
U
e
V/mA
24/50
-
24/50
12/100
Rated operational current
AC-11
230 V
I
e
A
6
-
6
6
AC-13
250 V
I
e
A
6
-
6
-
400 V
I
e
A
2
-
2
-
DC-11
230 V
I
e
A
4
-
-
1
DC-13
60 V
I
e
A
4
-
4
-
110 V
I
e
A
2
-
2
-
230 V
I
e
A
0.5
-
0.5
-
Rated insulation voltage
U
i
V AC
440
440
440
440
Minimum operating voltage per contact
U
min
V DC
-
-
-
-
Rated impulse withstand voltage
U
imp
kV
-
-
-
-
Rated conditional short-circuit current
with 6 A back-up fuse
I
k
kA
-
-
-
-
Max. admissible back-up fuse
A gL
6
Inherently
short-circuit-proof
6
6
Lifespan
Mechanical
Operations > 6000
> 4000
> 6000
-
Inrush current
AC
A
-
38
-
-
Duty factor AC
ms
-
2.1
-
-
DC
A
-
34
-
-
Duty factor DC
ms
-
2
-
-
Mechanical
Standard front dimension
mm
45
45
45
45
Device height
mm
90
90
90
90
Mounting width
mm
8.8 (0.5 SU)
17.5 (1 SU)
8.8 (0.5 SU)
8.8 (0.5 SU)
Mounting
Top-hat rail to IEC/EN 60715
Protection type
Enclosed
IP40
Circuit-breaker
IP20
Terminal capacity
Solid
mm
2
1 x (1 - 25)
2 x (1 - 4)
1 x (1 - 25)
2 x (1 - 4)
2 x (0.5 - 2.5)
1 x (0.5 - 2.5)
1 x 2.5
2 x 1.5
Flexible
mm
2
1 x (1 - 25)
2 x (1 - 4)
1 x (1 - 25)
2 x (1 - 4)
2 x (0.5 - 2.5)
1 x (0.5 - 2.5)
1 x 2.5
2 x 1.5
Tightening torque of the terminal screws
Nm
0.8
3
0.8
0.8
AZ-X..., FI-X...
