Circuit-breakers, fuses
Leakage current meter
2010 CA08103002Z-EN
19/69
Leakagecurrentmeter
PDIM
Electrical
Standards Conforming with DIN/EN 62020
Rated operational current Ie A 40, 100
Response behavior (adjustable) Non-delayed
Type G 10 ms delayed
Type S 40 ms delayed - selective
Rated operating voltage Ue V AC 230/400 50/60 Hz
240/415 50/60 Hz
Rated fault currents IΔn mA 30, 100, 300, 500, 1000
Sensitivity Alternating and pulsed current
Rated insulation voltage Ui V 440
Rated short-circuit strength Inc kA 10
Max. admissible back-up fuse
In = 40 A A gG/gL Short-circuit: 63
overload: 40
In = 100 A A gG/gL Short-circuit: 100 A
Overload: 63 A
Switching contacts Potential-free 10 A / 230 ∼
Response behavior of contacts 1: 30 - 50 % I Δn
2: > 50 % IΔn
Lifespan
Electrical Operations ≧ 4000
Mechanical Operations ≧ 20000
Mechanical
Standard front dimension mm 45
Device height mm 80
Mounting width mm 70 (4 SU)
Mounting position Any
Mounting Quick attachment with two engagement positions for top-hat rail to
IEC/EN 60715
Protection type
Enclosed IP40
Protection type In moisture-proof enclosure IP54
Terminals top and bottom Twin-purpose terminals
Terminal protection Busbar tag shroud to BGV A3, ÖVE-EN 6
Terminal capacity (1, 2, 3, 4, 5, 6, N, N)
Solid mm 2 1.5 - 35
Stranded mm 2 2 x 16
Terminal cross-section of switching contacts mm 2 0.25 - 1.5
Thickness of busbar material mm 0.8 - 2
Admissible ambient temperature range °C -25 to +40
Climatic proofing According to IEC/EN 61008
PDIM
