Residualcurrentdevice, remotemonitoringunit
mRB6... mRB4...
Electrical
Standards IEC/EN 61009 IEC/EN 61009
Tripping A 250 (8/20m) non-delayed surge resistant
Rated operating voltage Ue V AC 230/400 230/400
Rated frequency f Hz 50 50
Rated fault currents IDn mA 30, 100, 300 30, 100, 300
Rated fault non-tripping current 0.5 x I dn 0.5 x I d n
Sensitivity DC and pulsed current
Rated switching capacity Icn kA 6 4.5
Rated operational current Ie A 6 - 25 6 - 25
Rated impulse withstand voltage Uimp kV 4 (1.2/50 ms) 4 (1.2/50 ms)
Characteristic B, C, D C, D
Maximum back-up fuse as short-circuit protective
device
A gL 100 100
Selectivity class 3 3
Lifespan
Electrical Operations > 4000 > 4000
Mechanical Operations > 20000 > 20000
Mechanical
Standard front dimension mm 45 45
Device height mm 80 80
Terminal protection Busbar tag shroud to VBG4
Mounting width mm 70 (4 SU) 70 (4 SU)
Mounting Tristable slide catch allows removal from an existing assembly.
Protection type
Circuit-breaker IP20 IP20
Enclosed IP40 IP40
Terminals top and bottom Twin-purpose terminals Twin-purpose terminals
Terminal capacity
Solid mm2 1 - 25 1 - 25
Thickness of busbar material mm 0.8 - 2 0.8 - 2
Admissible ambient temperature range °C -25 - +40 -25 - +40
Climatic proofing According to IEC 68-2 (25 – 55 °C, 90 – 95 % rel. humidity)
Z-CC/2CO
Electrical
Power supply VDC 12 - 24 ( ≧ 10 - ≦ 30)
Power consumption W 1.5 - 6
Temperature sensor Incl. 9 pole Sub-D plug (for RS232 interface)
Measurement range -10 °C – +50 °C, accuracy: ± 2 °C
Outputs 2 floating relay outputs
AC: 5 A at 250 AC
DC: 5 A at 30 V DC, 0.3 A at 110 V DC and 0.12 A at 220 V DC
Max. switching duty AC15 at 230 V DC: 500 VA
Inputs 4; max. 12 – 24 V DC (2 – 4 mA)
isolated (optocoupler)
Ethernet interface Required for parameterization with a PC (web browser).
For connecting PC and Z-CC/2CO a crossover network cable is required
(DNW-PX/0200/RJ45/RJ45).
RS232 interface 9 pole Sub-D plug for connecting an external temperature sensor
Green LED ON Modem status LED (on registration in the GSM network the LED flashes every
3 seconds)
Red LED ON Modem activity LED (flashes when SMS is being sent or received)
Mechanical
Standard front dimension mm 45
Device height mm 97
Mounting width mm 105
Mounting Quick attachment for top-hat rail EN 50022
Protection type
Enclosed IP40
mRB4..., mRB6..., Z-CC/2CO
