Circuit-breakers, fuses
Remote switching modules, miniature circuit-breakers
2010 CA08103002Z-EN
19/73
Remote switchingmodules,miniaturecircuit-breakers
FAZ/FIP-XAWM FAZ/FIP-XDWM
Electrical
Operating voltage range
V AC 220 - 240 -
V DC - 48
Rated frequency f Hz 50/60 -
Relay output for alarm, 250 V AC, floating A 5 5
Function Automatic control
Function selector Automatic 5 x, OFF/RESET
Mechanical
Standard front dimension mm 45 45
Device height mm 80 80
Mounting width mm 70 70
Mounting Top-hat rail to IEC/EN 60715
Protection type
Enclosed IP40
Terminal protection Busbar tag shroud to BGV A2
Terminals Lift terminals
Terminal capacity
Solid mm 2 2 x 1.5
1 x 2.5
2 x 1.5
1 x 2.5
Flexible mm 2 2 x 1.5
1 x 2.5
2 x 1.5
1 x 2.5
FAZ-...-NA
FAZ-...-RT
Electrical
Standards UL 489, CSA C22.2 No.5, IEC 60947-2
Rated operating voltage
UL/CSA 0.5 - 25 A V AC 277/480 Y
UL/CSA 32 - 40 A V AC 240
UL/CSA (per pole) V DC 48
IEC V AC 240/415
Rated frequency f Hz 50/60
Rated breaking capacity
IEC kA 15
Characteristic B, C, D
Lifespan Operations > 20000
Mains voltage connection Any (top/bottom)
Mechanical
Standard front dimension mm 45
Device height mm 105
Mounting width per pole mm 17.7
Mounting Quick attachment with two engagement positions for top-hat rail to IEC/EN 60715
Terminals top and bottom Twin-purpose terminals
Terminal capacity
Solid AWG 18 - 6
Flexible AWG 18 - 10
Mounting position Any
Calibration temperature
UL 489, CSA C22.2 No. 5 °C 40
IEC 60947-2 °C 30
FAZ-FIP, FAZ-...-NA, FAZ-...-RT
