19/78 Circuit-breakers, fuses
Fuse switch-disconnectors, fuse material
2010 CA08103002Z-EN
Fuse switch-disconnectors, fusematerial
VLC14 VLC22
Electrical
Number of poles 1P
1P+N
2P
3P
3P+N
1P
1P+N
2P
3P
3P+N
Rated operating voltage V AC 690 690
Rated operational current Ie A 50 100
Rated conditional short-circuit current Ie kA 100 100
Rated frequency f Hz 50 50
Utilization category AC 22 B AC 21 B
Rated impulse withstand voltage Uimp kV 8 8
Max. permissible heat dissipation of the fuse W gG: 5, aM: 3 gG: 9.5, aM: 7
Mechanical
Standard front dimension mm 45 45
Device height mm 94 121
Mounting width mm 27/per pole 36/per pole
Weight g 1P 100
1P+N 222
2P 201
3P 308
3P+N 437
1P 160
1P+N 355
2P 310
3P 480
3P+N 680
Mounting Quick attachment for top-hat rail
IEC/EN 60715
Protection type
Enclosed IP20
Terminals Lift terminals
Terminal capacity
Solid mm2 1.5-10 2.5-35
Temperature range °C -25 ... +60 -25 ... +60
Terminal screw tightening torque
Tightening torque Nm Max. 2 Max. 2.5
Pollution degree 1 1
Track resistance CTI 400 CTI 400
Z-D01/SE Z-D02/SE
Electrical
Rated operating voltage V AC 400 400
V DC 220 220
Utilization category gG (gL) gG (gL)
Rated frequency f Hz 45-65 45-65
Rated insulation voltage Ui V 2500 2500
Rated short-circuit switching capacity 50 kA (AC)
8 kA (DC)
50 kA (AC)
8 kA (DC)
Z-SLS/B Z-SLS/B24 Z-SLS/TR-SET
Electrical
Rated operating voltage V DC - 24 -
Rated operating voltage V AC 60 - 400 24 400
Utilization category gG (gL) gG (gL) -
Test voltage kV 5 5 5
Rated uninterrupted current Iu A - - 63
VLC, Z-DO..., Z-DO1, Z-DO2, Z-SLS...
