Fusematerial
Z-SLS/NE0Z Z-SLK/NE0Z
Electrical
Number of poles 1P
1P+N
2P
3P
3P+N
1P
1P+N
2P
3P
3P+N
Rated operating voltage V DC 1P up to 110V / 2P up to 220V
Rated operating voltage V AC 400 400
Rated operational current Ie A 63 63
Rated uninterrupted current Iu A 63 63
Rated short-circuit making capacity 50 kArms 50 kArms
Normally open contact - 5A/250V
Switching category AC 22 B, DC 21 B AC 22 B, DC 21 B
Overvoltage category IV IV
Rated impulse withstand voltage Uimp kV 6 6
Current heat loss per current path at Ie W 0.5 0.5
Heat dissipation
Heat dissipation per contact with fuse link at Ie W 7.5 7.5
Relay section electrical
Operating voltage range V AC - 24 - 240
Operational voltage tolerance - g10%
Power consumption VA - 5
Frequency Hz - 50-60
Function display - Mains: 1 LED
Fault: 1 LED
Duty factor % - 100
Response delay ms - Approx. 100
Recovery time tW ms - Approx.100
Relay contacts - 2 changeover contacts, 5A/250V
Overvoltage category - III
Auxiliary contacts
Rated impulse withstand voltage Uimp kV - 4
Mechanical
Standard front dimension mm 45 45
Device height mm 86 86
Mounting width mm 27/per pole (1.5 SU) 27/per pole (1.5SU) + 27
Weight g 1P 113
1P+N 225
2P 224
3P 450
3P+N 472
1P 224
2P 345
3P 450
3P+N 472
Mounting Quick attachment for top-hat rail IEC/EN 60715
Protection type in fitted state IP20 IP20
Terminals Lift terminals Lift terminals
Terminal capacity
Solid mm2 1.5 - 35 1.5 - 35
Temperature range °C -25 ... +60 -25 ... +60
Flammability classification to EN 60730 V0, glow-wire test 960°C
Terminal screw tightening torque Nm Max. 4.5 Max. 4.5
Pollution degree 3 3
Track resistance CTI 600 CTI 600
Relay section mechanical
Terminals Lift terminals Lift terminals
Terminal capacity
Solid mm2 - 0.14 - 4
Flexible mm2 - 0.14 - 2.5
Terminal screw tightening torque Nm 0.5 - 0.7
Z-SLS, Z-SLK
