19/80 Circuit-breakers, fuses

LV h.b.c. fuse switch-disconnectors

2010 CA08103002Z-EN

www.eaton.com

LVh.b.c. fuse switch-disconnectors

GST...00-160

GST…1

GST…2

GST…3

General

Standards

IEC/EN 60947-3

Climatic proofing

Damp heat, constant, to IEC 60068-2-78

Damp heat, cyclic, to IEC 60068-2-30

Ambient temperature

°C

-25 ... +55

-25 ... +55

-25 ... +55

-25 ... +55

Installation altitude

m

max. 2000

max. 2000

max. 2000

max. 2000

Mounting position

Vertical, horizontal

Overvoltage category/pollution degree

III/3

III/3

III/3

III/3

Busbar tag shroud at the front

Operational status

IP20

IP20

IP20

IP20

Front cover open

IP10

IP10

IP10

IP10

Direction of incoming supply

Any

Weight

kg

0.72 GSTA

0.93 GST

2.5 GSTA

4.4 GST

3.3 GSTA

5.3 GST

4.6 GSTA

6.6 GST

Contacts

Rated operating voltage

U

e

V AC

500

690

500

690

500

690

500

690

Rated operating voltage

U

e

V DC

220

440

220

440

220

440

220

440

Rated operational current

I

e

A

160

100

250

200

400

315

630

500

Rated frequency

Hz

40 - 60

40 - 60

40 - 60

40 - 60

Rated conditional short-circuit current AC

kA

rms

50

50

50

50

Rated conditional short-circuit current, DC

kA

rms

25

25

25

25

Utilization category AC-22B

Rated making capacity

A

480

300

750

600

1200

945

1890

1500

Rated breaking capacity

A

480

300

750

600

1200

945

1890

1500

Utilization category DC-21B

Rated making capacity

A

150

300

475

750

Rated breaking capacity

A

150

300

475

750

Lifespan, electrical

Operations

300

200

200

200

Lifespan, mechanical

Operations

1700

1400

800

800

Heat dissipation at I

th

AC, without NH-SE

W 6.9

2.7

12.9

8.3

27

16.7

52

32.8

Heat dissipation at I

th

DC, without NH-SE

W 4.6

1.8

8.6

5.5

18

11.2

34.7

21.8

Rated insulation voltage

U

i

V AC

750

750

750

750

Max. fuse link

Size

NH00

NH1

NH2

NH3

Max. rated operational current, gL/gG

A

160

250

400

630

Max. admissible heat dissipation, NH-SE

P

v

W 12

23

34

48

Terminal capacity

Box terminal

Stranded

mm

2

1.5 - 70

-

-

-

Copper strip

Number of layers x width x thickness

mm 6 x 9 x 0.8

-

-

-

Tightening torque

Nm 2.6

-

-

-

Flange connection

Bolt diameter

-

M10

M10

M10

Cable lug

mm -

1 x 25 - 150

1 x 25 - 240

1 x 25 - 300

Flat rail

mm -

30 x 10

30 x 10

40 x 10

Tightening torque

Nm -

30 - 35

30 - 35

30 - 35

Box terminal

Stranded copper

mm

2

1.5 - 70

25 - 150

25 - 240

25 - 300

Copper strip

Number of layers x width x thickness

mm -

6 x 16 x 0.8

10 x 16 x 0.8

11 x 21 x 1

Tightening torque

Nm -

9.5

23

23

Clamp-type cable terminal

Stranded aluminum/copper

mm

2

-

70 - 150

120 - 240

120 - 300

Tightening torque

Nm -

4.5

11

11

Double clamp-type terminal

Stranded aluminum/copper

mm

2

-

2 x (70 - 95)

2 x (120 - 150)

2 x (120 - 240)

Tightening torque

Nm -

4.5

11

11

GST
