Fuse switch-disconnectors, fusematerial
C10-FD/...
Electrical
Standards IEC/EN 60947-1 Ed. 4.0, EN 60947-1:1999+A1:2000+A2:2001
IEC/EN 60947-3 Ed. 2.1, EN 60947-3:1999+A1:2001
No. of poles 1, 2
Rated voltage Ue V DC 1000
Rated operational current Ie A 20
Rated conditional short-circuit current kA 10
Utilization category DC 20 B
Rated insulation voltage Ui V DC 1000
Overvoltage category ll
Rated impulse withstand voltage Uimp kV 4
Current heat loss per contact without fuse W 0.9
Max. heat dissipation of fuse W 3
Mechanical
Standard front dimension mm 45
Device height mm 83.3
Mounting width mm 17.5/pole
Weight
1P g 58
2P g 70
Mounting Quick attachment for top-hat rail IEC/EN 60715
Protection type IP20
Terminals top and bottom Lift terminals
Terminal cross-section 0.5 - 10 mm2
AWG 20 - 8
Tightening torque of the terminal screws Nm 1.5
Ambient temperature range °C -25 - +40
Flammability classification Glow wire 960 °C
Pollution degree 2
Track resistance CTI 450
Z-C10/SE
10 x 38
Z-C12/SE
14 x 51
Z-C22/SE
22 x 58
Electrical
Standards IEC 60269-1 and IEC 60269-2-1
Utilization category gG (gL) gG (gL) gG (gL)
Rated voltage Un V AC 1 - 25 A/500
32 A/400
2 - 32 A/690
40 - 50 A/500
16 - 40 A/690
50 - 100 A/500
Utilization category aM aM aM
Rated voltage Un V AC 1 - 16 A/500
20 - 32 A/400
2 - 25 A/690
32 - 50 A/500
16 - 50 A/690
80 - 100 A/500
Rated frequency f Hz 50 50 50
Rated short-circuit breaking capacity kA 100 100 100
Z-C10/SE-.../PV
10 x 38
Electrical
Standards IEC 60269-1 and IEC 60269-4
Rated voltage Un V DC 6 - 20 A/1000
25 A/900
Rated short-circuit breaking capacity kA 30
τ = L/R ms 2
C10-FD/..., Z-C.../SE
