19/70 Circuit-breakers, fuses
Auxiliary contacts, shunt releases
2010 CA08103002Z-EN
www.eaton.comAuxiliarycontacts, shunt releases
FAZ-XHIN11
FAZ-XHINW1 FAZ-XAM002
FAZ-XAA-C
FAZ-XUA
Electrical
Rated operating voltage
U
e
V AC
250
250
250
-
115, 230, 400
Contact function
1 N/O + 1 NC 1 C
2 C
-
-
Voltage range
V AC
-
-
-
12 - 110
110 - 415
-
Closing threshold
x U
n
-
-
-
-
0.8
Tripping threshold
x U
n
-
-
-
-
0.5
Rated frequency
f
Hz
50/60
50/60
50/60
50/60
50/60
Rated operational current
I
e
A
6
6
4
-
-
Thermal rated operational current
I
th
A
6
6
4
-
-
Rated operational current
AC-12
I
e
A
3 (250 V AC)
3 (250 V AC)
3 (250 V AC)
-
-
AC-15
I
e
A
2 (250 V AC)
2 (250 V AC)
2 (250 V AC)
-
-
DC-13
I
e
A
0.5 (110 V DC)
0.5 (110 V DC)
0.5 (110 V DC)
-
-
Rated insulation voltage
U
i
V AC
250
250
250
-
-
Minimum operating voltage per contact
U
min
V DC
5
5
5
-
-
Rated impulse withstand voltage
(1.2/ 50
m
)
U
imp
kV
2.5
2.5
2.5
-
-
Rated conditional short-circuit current
with 6 A back-up fuse
I
k
kA
1
1
1
-
-
Max. admissible back-up fuse
A gL
6
6
4
Mechanical
Standard front dimension
mm
45
45
45
45
45
Device height
mm
80
80
80
80
80
Mounting width
mm
8.8 (0.5 SU)
8.8 (0.5 SU)
8.8 (0.5 SU)
17.5 (1 SU)
17.5 (1 SU)
Mounting
Max. 2 × on
switching
device
Max. 2 × on
switching
device
On switching
device
IEC/EN 60715
top-hat rail
IEC/EN 60715
top-hat rail
Protection type
Enclosed
IP40
Terminal protection
Busbar tag shroud to BGV A2
Terminals
Lift terminals
Lift terminals
Lift terminals
Twin-purpose
terminals
Twin-purpose
terminals
Terminal capacity
Solid
mm
2
0.5 - 2.5
0.5 - 2.5
0.5 - 2.5
1 - 2.5
2 x (1 - 2.5)
Flexible
mm
2
0.5 - 2.5
0.5 - 2.5
0.5 - 2.5
1 - 2.5
2 x (1 - 2.5)
Tightening torque of
terminal screws
Nm
F
1.2
F
1.2
0.8 - 1.0
2.4
0.8
FAZ-XHIN, FAZ-X...
