Control relays, multi-function display
Basic devices, expansion devices
2010
CA08103002Z-EN
www.eaton.com...R..., MFD...R...
...R...,MFD...R...Basicdevices,expansiondevices
EASY202-RE
EASY410-DC-RE
EASY512-..-R..
MFD-R.. MFD-AC-R..
EASY618/719-..-R..
EASY8..-…-R…
Relay outputs
Number
2
4
6
Outputs in groups of
2
1
1
Parallel switching of outputs to increase performance
Not permissible Not permissible
Not permissible
Protection of an output relay
Miniature circuit-breaker B16 or fuse 8 A (slow)
Potential isolation
From power supply
Yes
Yes
Yes
From the inputs
Yes
Yes
Yes
Electrical isolation in groups
Yes
Yes
Yes
Safe isolation according to EN 50178
V AC
300
300
300
Basic insulation
V AC
600
600
600
Lifespan, mechanical
Operations x 10
6
10
10
10
Contacts
Conventional thermal current (10 A UL)
A
8
8
8
Recommended for load: 12 V AC/DC
mA
> 500
> 500
> 500
Short-circuit proof p.f. = 1, characteristic B16 at 600 A
A
16
16
16
Short-circuit proof p.f. = 0.5 - 0.7; characteristic B16 at 900 A
A
16
16
16
Rated impulse withstand voltage U
imp
contact coil
kV
6
6
6
Rated operating voltage
U
e
V AC
250
250
250
Rated insulation voltage
U
i
V AC
250
250
250
Safe isolation to EN 50178 between coil and contact
V AC
300
300
300
Safe isolation to EN 50178 between two contacts
V AC
300
300
300
Making capacity
AC-15, 230 V AC, 3 A
Operations
300000
300000
300000
DC-13, 24 V DC, 5 A, 0.1 Hz
Operations
200000
200000
200000
Breaking capacity
AC–-15, 250 V AC, 3 A (600 ops./h)
Operations
300000
300000
300000
DC-13, L/R ≦ 150 ms, 24 V DC, 1 A (500 S/h)
Operations
200000
200000
200000
Filament bulb load
1000
W at 230/240 V AC
Operations
25000
25000
25000
500
W at 115/120 V AC
Operations
25000
25000
25000
Fluorescent lamp load
Fluorescent lamp load 10 x 58 W at 230/240 V AC
With upstream electrical device
Operations
25000
25000
25000
Uncompensated
Operations
25000
25000
25000
Fluorescent lamp load 1 x 58 W at 230/240 V AC, conventionally
compensated
Operations
25000
25000
25000
Switching frequency
Mechanical operations
x 10
6
10
10
10
Switching frequency
Hz
10
10
10
Resistive load/lamp load
Hz
2
2
2
Inductive load
Hz
0.5
0.5
0.5
UL/CSA
Continuous current at 240 V AC
A
10
10
10
Continuous current at 24 V DC
A
8
8
8
AC
Control circuit rating codes (utilization category)
B 300 Light Pilot Duty
Max. rated operational voltage
V AC
300
300
300
Max. thermal continuous current p.f. = 1 at B 300
A
5
5
5
Max. make/break
p.f. ≠ capacity 1 at B 300
VA
3600/360
3600/360
3600/360
DC
Control circuit rating codes (utilization category)
R 300 Light Pilot Duty
Max. rated operational voltage
V DC
300
300
300
Max. thermal continuous current at R 300
A
1
1
1
Max. make/break capacity
at R 300
VA
28/28
28/28
28/28
Notes
For additional technical data EASY5… and EASY7…￫AWB2528-1508D, EASY8…
￫AWB2528-1423D, MFD￫AWB2528-1480D
