Control relays, multi-function display
Switched-mode power supply units
2010
CA08103002Z-EN
www.eaton.com...POW
Rating data
Efficiency
%
> 80
> 83
> 85
> 85
Power consumption
W Normally 7
Normally 35
Normally 70
Normally 115
Heat dissipation
W Normally 1
Normally 5
Normally 10
Normally 18
Input current
Rated input current value 115/230 V AC
A
Approx. 0.17/0.05 Approx. 0.6/0.3
Approx. 0.8/0.4
Approx. 1/0.5
Inrush current at 230 C 25 V
A
< 5
< 18
< 30
< 30
Output voltage
12
V DC (reference voltage)
Rated value
V DC
12
–
–
–
Tolerance
%
± 4
–
–
–
Switching peaks
mV
SS
< 7
–
–
–
Effect of input voltage
%
± 1
–
–
–
Effect with 25 – 100 % load change
%
± 1
–
–
–
24
V DC
Rated value
V DC
24
24
24
24
Tolerance
%
± 3
± 3
± 3
± 3
Switching peaks 115/230
mV
SS
< 50/30
< 5
< 5
< 5
Effect of input voltage
%
± 1
± 1
± 1
± 1
Effect with 25 – 100 % load change
%
± 1
± 2
± 2
± 2
Can be connected in parallel to increase power
–
–
Yes
Yes
Yes
Output current
12
V DC (reference voltage)
Output current
mA
0 - 20
–
–
–
Effectiveness of current limitation
mA
20
–
–
–
Reduction of output voltage after
current limitation
V
< 12
–
–
–
Overload proof
Yes, by current
limitation perma-
nently short-circuit
proof
–
–
–
Proof against sustained short circuit
Yes
–
–
–
24
V DC
Output current
A
0 - 0.35
0 - 1.25
0 - 2.5
0 - 4.2
Effectiveness of current limitation
A
> 0.4
> 1.5
> 2.8
> 4.8
Reduction of output voltage after
current limitation
V
–
< 18
< 18
< 18
Overload proof
Yes, by current limitation
Proof against sustained short circuit
Yes, hickup-mode Yes, hickup mode, approx. 2 Hz
Special load conditions
Lamp load, cold, 24 V DC
W 2
10
–
–
Base load present
W 1
5
–
–
Behavior in the event of emergency switch off in 24 V
circuit, switch off using contactor (contactor load,
no damage)
W 6
30
–
–
Indication
Indication of output voltage
(
LED, continuous green light = OK)
V DC
24
24
24
24
EASY200-POW EASY400-POW EASY500-POW EASY600-POW
EASY430-POW
