12/48 Control relays, multi-function display
Ethernet gateway
2010 CA08103002Z-EN
EASY209-SE, EASY256-HCI
EASY209-SE,EASY256-HCIEthernetgateway
EASY209-SE
Power supply
Rated operational voltage Ue V 24 (-15/+20 %)
Permissible range V DC 20.4…28.8
Ripple % ≦ 5
Max. current consumption (at 24 V DC) mA Normally 65
Voltage dips (IEC/EN 61131-2) ms –
Heat dissipation at 24 V DC W 1.7
Protection against polarity reversal
Power supply Yes
LED indicators
Supply Front-LED Power: ON
LED display Front-LED COM active: flashes
RJ-45 socket, top No Activity: OFF, Amber: Half Duplex, Green: Full Duplex
RJ-45 socket, bottom No Link: OFF, Amber: 10 MBit/s, Green: 100 MBit/s
Gateway ready for operation –
Power supply SmartWire (contactor) –
Network Status (easyNet/CANopen) –
Status SmartWire LED –
Reset Front: per pushbuttons > 2s
Strain relief By cable tie in fastener
Network
Terminal type –
Potential isolation –
Bus protocol –
Bus terminating resistors –
Bus addresses Default settings Ethernet:
IP adress 0.0.0.0 SUBNET screen: 255.255.0.0 coupling unit
address 0.0.0.0 remote address 0.0.0.0
