Control relays, multi-function display
Bus modules
2010 CA08103002Z-EN
...ASI/DP/CO/DN 12/45
...ASI/DP/CO/DNBusmodules
EASY205-ASI EASY221-CO
EASY204-DP EASY222-DN
General
Standards EN 55011, EN 55022, IEC/EN 61000-4,
IEC 62026
EN 55011, EN 55022, IEC/EN 61000-4,
EN 50325
EN 55011, EN 55022, IEC/EN
61000-4,IEC 61158
EN 55011, EN 55022, IEC/EN
61000-4,IEC 62026
Dimensions (W x H x D) mm 35.5 x 90 x 58 (2 space units) 35.5 x 90 x 58 (2 space units)
Weight kg 0.12 0.15 0.15
Mounting Top-hat rail IEC/EN 60715, 35 mm or screw fixing using fixing brackets ZB4-101-GF1
(accessories).
Terminal capacity
Solid mm2 0.2 - 4 (AWG 22 - 12) 0.2 - 4 (AWG 22 - 12)
Flexible with ferrule mm2 0.2 - 2.5 (AWG 22 - 12) 0.2 - 2.5 (AWG 22 - 12)
Flat-blade screwdriver mm 3.5 x 0.8 3.5 x 0.8
Max. tightening torque Nm 0.6 0.6
Ambient climatic conditions
Operating ambient temperature °C -25…55, low temperatures to IEC 60068-2-1, high temperatures to IEC 60068-2-2
Condensation Prevent condensation by means of suitable measures
Storage °C -40 - 70 -40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 - 95 5 - 95
Air pressure (in operation) hPa 795 - 1080 795 - 1080
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4) IP20 IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm Hz 10 - 57 10 - 57
Constant acceleration, 2 g Hz 57 - 150 57 - 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18 18
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 1 1
Mounting position Vertical or horizontal Vertical or horizontal
Electromagnetic compatibility (EMC)
Overvoltage category/pollution degree II/2 II/2
Electrostatic discharge (ESD), to IEC EN 61000-4-2
Air discharge kV 8 8
Contact discharge kV 6 6
Electromagnetic fields (IEC/EN 61000-4-3, RFI) V/m 10 10
Radio interference suppression EN 55011 Class B, EN 55022 Class B
Burst to IEC/EN 61000-4-4
AS-Interface cables kV 2 –
Supply cables kV – 2
Signal cables kV – 2
Power pulses (surge), to IEC/EN 61000-4-5 kV – 0.5 (supply cables,
symmetrical)
0.5 (supply cables, symmetrical)
Radiated RFI, to IEC/EN 61000-4-6 V 10 10
Insulation resistance
Clearance in air and creepage distances EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance EN 50178 EN 50178
