Control relays, multi-function display
Ethernet coupling unit, upstream device
2010
CA08103002Z-EN
www.eaton.comEASY209-SE, EASY256-HCI
12/47
EASY209-SE,EASY256-HCIEthernetcouplingunit,upstreamdevice
EASY209-SE
EASY256-HCI
General
Standards
EN 55011, EN 55022, IEC/EN 61000-4, EN 50178
Dimensions (W x H x D)
mm
35.5
x 90 x 58 (2 space units)
35.5
x 90 x 58 (2 space units)
Weight
kg
0.15
0.15
Mounting
Top-hat rail IEC/EN 60715, 35 mm or screw fixing using fixing brackets
ZB4-101-GF1 (accessories).
Channels
Number
–
6
Voltage range for U
e
0 - 264
Current increase 115/230 V AC
mA
–
4/6
Delay time
ms
–
40/37
Cable length
m
–
100
Parallel switching of outputs to increase performance
–
Several possible (Off-delay extended
depending on the number of parallel
channels)
Type of resistance
–
Capacitive
Terminal capacity
Solid
mm
2
0.2 - 4 (
AWG 22 - 12)
0.2 - 4 (
AWG 22 - 12)
Flexible with ferrule
mm
2
0.2 - 2.5 (
AWG 22 - 12)
0.2 - 2.5 (
AWG 22 - 12)
Flat-blade screwdriver
mm
3.5
x 0.8
3.5
x 0.8
Max. tightening torque
Nm
0.6
0.6
Data cable
Solid
mm
2
0.25/1.5 (
AWG 24/16)
–
Flexible with ferrule
mm
2
0.14/ 1 (
AWG 26/17)
–
Ambient climatic conditions
Operating ambient temperature
°C
-25…55
-25…55,
low temperatures to
IEC 60068-2-1, high temperatures to
IEC 60068-2-2
Condensation
Prevent condensation by means of suitable measures
Storage
°C
-40 - 70
-40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30)
%
5 - 95
5 - 95
Air pressure (in operation)
hPa
795 - 1080
795 - 1080
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4)
IP20
IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm
Hz
10 - 57
10 - 57
Constant acceleration, 2 g
Hz
57 - 150
57 - 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks
18
18
Drop to IEC/EN 60068-2-31
Drop
height
mm
50
50
Free fall, packaged (IEC/EN 60068-2-32)
m
1
1
Mounting position
Vertical or horizontal
Electromagnetic compatibility (EMC)
Overvoltage category/pollution degree
II/2
II/2
Electrostatic discharge (ESD), to IEC EN 61000-4-2
Air discharge
kV
8
8
Contact discharge
kV
6
6
Electromagnetic fields (IEC/EN 61000-4-3, RFI)
V/m
RS-232 line unshielded: 3,
shielded: 10
10
Radio interference suppression
EN 55011 Class B, EN 55022 Class B
Burst to IEC/EN 61000-4-4
AS-Interface cables
kV
–
–
Supply cables
kV
2
–
Signal cables
kV
–
–
Ethernet interface cable
kV
2
–
COM interface cable
kV
2
–
Power pulses (surge), to IEC/EN 61000-4-5
kV
1 (
supply cables, symmetrical)
2 (
supply cables, symmetrical,
EASY…DC)
Radiated RFI, to IEC/EN 61000-4-6
V
RS-232 line unshielded: 3,
shielded: 10
10
Insulation resistance
Clearance in air and creepage distances
EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance
EN 50178
EN 50178
