12/46 Control relays, multi-function display
Bus modules
2010 CA08103002Z-EN
...ASI/DP/CO/DN
EASY205-ASI EASY204-DP EASY221-CO EASY222-DN
Power supply
Rated operational voltage Ue V 26.5 - 31.6 24 (-15/+20 %) 24 (-15/+20 %) 24 (-15/+20 %)
Permissible range V DC 20.4…28.8 20.4…28.8 20.4…28.8
Total power consumption of the
AS interface
mA ≦ 30 – – –
Ripple % – ≦ 5 ≦ 5 ≦ 5
Max. current consumption (at 24 V DC) mA – Normally 200 Normally 200 Normally 200
Voltage dips (IEC/EN 61131-2) ms – 10 10 10
Heat dissipation at 24 V DC W – 4.8 4.8 4.8
Protection against polarity reversal
AS-Interface
protection against polarity reversal
Yes – – –
AS-Interface profile 7F (hex) – – –
Slave address 0 - 31
Addressing unit interface 3.5 mm socket – – –
Power supply – Yes Yes Yes
LED indicators
Supply Power: green Power LED (POW):
green
RUN LED (RUN): green Module status LED
(MS): green
LED display Com Error: red LED PROFIBUS-DP
(BUS): red
LED ERROR (ERR): red Network status LED
(NS): red/green
I/O addresses
easy700/easy800 contact and coil
↔AS-Interface
S1 → input 0
S2 → input 1
S3 → input 2
S4 → input 3
R1 ← outputs 0
R2 ← outputs 1
R3 ← outputs 2
R4 ← outputs 3
R5 ← PARAMETEROUTPUT 0
R6 ← PARAMETEROUTPUT 1
R7 ← PARAMETEROUTPUT 2
R8 ← PARAMETEROUTPUT 3
– – –
Network
Terminal type – SUB-D 9 pole, socket RJ45 5 pole, pluggable screw
terminal
Potential isolation – Between bus and power supply (simple), between bus and power supply and
easy base unit (safe isolation)
Function – PROFIBUS-DP slave CANopen slave DeviceNet slave
Interface – RS485 CAN CAN
Bus protocol AS-Interface PROFIBUS-DP CANopen DeviceNet
Baud rates – Automatic search up to
12 MBit⁄s
Automatic search up to
1 MBit⁄s
Automatic search up to
500 kBit⁄s
Bus terminating resistors – Can be connected via
plug
Separate external bus
termination
required (120 Ω)
Separate external bus
termination
required (120 Ω)
Bus addresses – 1 - 126 can be
addressed via easy
base unit with display or
via EASY-SOFT
1 - 127 can be
addressed via easy
basic units with display
or via easySoft
0 - 63 can be
addressed via easy
basic units with display
or via easySoft
Services
Cyclical – All data R1 - R16, S1 - S8
Acyclical – Read⁄write, time, day, daylight saving time
All parameters of the EASY function relay
