Multi-function display

I/O modules

2010

CA08103002Z-EN

www.eaton.com

MFD-(AC)-R..., MFD-T

MFD-R16

MFD-RA17

MFD-T16

MFD-TA17

MFD-T...P...

MFD-AC-R16

Digital inputs 24 V DC

Number

12

12

6

Inputs can be used as analog inputs

4 (

I7, I8, I11, I12)

4 (

I7, I8, I11, I12)

2 (

I11, I12)

Potential isolation

From power supply

No

No

No

Between digital inputs

No

No

No

From the outputs

Yes

Yes

Yes

From PC interface, memory card,

easy NET, easyLink

Yes

Yes

Yes

Rated operating voltage

U

e

V DC 24

24

24

On signal ”0”

U

e

V DC < 5.0 (I1 - I6, I9 - I10),

< 8 (I7, I8, I11, I12)

< 5.0 (I1 - I6, I9 - I10),

< 8 (I7, I8, I11, I12)

< 5.0 (I1 - I4),

< 8.0 (I11, I12)

On signal ”1”

U

e

V DC > 15.0 (I1 - I6, I9 - I10),

> 8.0 (I7, I8, I11, I12)

> 15.0 (I1 - I6, I9 - I10),

> 8.0 (I7, I8, I11, I12)

>15.0 (I1 - I4),

> 8.0 (I11, I12)

Input current on signal "1"

I1 to I6

mA 3.3 (at 24 V DC)

3.3 (

at 24 V DC)

I1 to I4

mA –

3.3 (

at 24 V DC)

I7, I8

mA 2.2 (at 24 V DC)

2.2 (

at 24 V DC)

I9, I10

mA 3.3 (at 24 V DC)

3.3 (

at 24 V DC)

I11, I12

mA 2.2 (at 24 V DC)

2.2 (

at 24 V DC)

2.2 (

at 24 V DC)

Delay time from 0 to 1

Debounce ON

ms

20

20

20

Debounce OFF

ms

Normally 0.1 (I1 - I4), normally 0.25 (I5 - I12)

Delay time from 1 to 0

Debounce ON

ms

20

20

20

Debounce OFF

ms

Normally 0.1 (I1 - I4),

normally 0.4 (I5, I6, I9,

I10), normally 0.2

(

I7, I8, I11, I12)

Normally 0.1 (I1 - I4),

normally 0.4 (I5, I6, I9,

I10), normally 0.2

(

I7, I8, I11, I12)

Normally 0.1 (I1 - I4),

normally 0.2 (I11, I12)

Cable length (unshielded)

m 100

100

100

Frequency counters

Number

4 (

I1, I2, I3, I4)

4 (

I1, I2, I3, I4)

4 (

I1, I2, I3, I4)

Counter frequency

kHz

< 3

< 3

< 3

Pulse shape

Square

Square

Square

Incremental counters

Number

2 (

I1 + I2, I3 + I4)

2 (

I1 + I2, I3 + I4)

2 (

I1 + I2, I3 + I4)

Counter frequency

kHz

≦ 3

≦ 3

≦ 3

Pulse shape

Square

Square

Square

Signal offset

90

°

90

°

90

°

High-speed counter inputs

Number

4 (

I1, I2, I3, I4)

4 (

I1, I2, I3, I4)

4 (

I1, I2, I3, I4)

Counter frequency

kHz

< 3

< 3

< 3

Pulse shape

Square

Square

Square

Cable length, shielded

m < 20

< 20

< 20

Digital inputs 115/230 V AC

Number

12

Status display

LCD display

(

if provided)

Potential isolation

From power supply

No

Between digital inputs

No

From the outputs

Yes

From PC interface, memory card,

easyNet, easyLink

Yes

Rated voltage L (sinusoidal)

On signal ”0”

V AC

0 - 40

On signal ”1”

V AC

79 - 264

Rated frequency

Hz

50 - 60

Input current on signal "1"

I1 to I12

mA

12

x 0.2 (at 115 V AC,

60

Hz), 12 x 0.5

(

at 230 V AC, 50 Hz)

Delay time

Delay time (0 - 1⁄1 - 0) I1 - I12, 50⁄60 Hz

10

⁄100

Max. admissible cable length (per input)

I1 to I12

m

Normally 60
