Control relays, multi-function display
Display/operating units, CPU, communication modules
2010
CA08103002Z-EN
www.eaton.comMFD-80, MFD-(AC)-CP...
MFD-80,MFD-(AC)-CP...Display/operatingunits,CPU,communicationmodules
MFD-80..
MFD-CP4…
MFD-AC-CP4..
MFD-CP10..
MFD-AC-CP8..
MFD-CP8..
General
Standards
EN 61000-6-1/-2/-3/-4, IEC 60068-2-6, IEC 60068-2-27
Dimensions (W x H x D)
mm 86.5 x 86.5 x 21.5 (with
buttons) 86.5 x 86.5 x 20
(
without buttons)
75
x 58 x 36.2
107.5
x 90 x 30
107.5
x 90 x 30
Weight
kg
0.13
0.16
0.14
0.14
Mounting
2
x 22.5 mm, display
fastened using
2
° threaded fixing
rings.
Wall thickness:
without top-hat rail
(
CPU) 1 – 6 mm
with top-hat rail
1 – 4
mm
Plug-fitted to the
display fixing shaft
Fitted on the fixing
shaft of the display
or on top-hat rail
according to
IEC/EN 60715, 35 mm
deep (without display)
Fitted on the fixing
shaft of the display
or on top-hat
rail according to
IEC/EN 60715, 35 mm
deep (without display)
Terminal capacity
Solid
mm
2
–
–
0.2
⁄4 (AWG 24 - 12)
0.2
⁄4 (AWG 24 - 12)
Flexible with ferrule
mm
2
–
–
0.2
⁄2.5 (AWG 24 - 12)
0.2
⁄2.5 (AWG 24 - 12)
Flat-blade screwdriver
mm –
–
3.5
x 0.6
3.5
x 0.6
Max. tightening torque
Nm –
–
–
–
Ambient climatic conditions
Operating ambient temperature
°C
-25 - 55,
low temperatures to IEC 60068-2-1, high temperatures to IEC 60068-2-2
Condensation
Prevent condensation by means of suitable measures
LCD display
(
clearly legible)
°C
-5 - 50
Storage
°C
-40 - 70
-40 - 70
-40 - 70
-40 - 70
Relative humidity, non-condensing
(
IEC/EN 60068-2-30)
%
5 - 95
5 - 95
5 - 95
5 - 95
Air pressure (in operation)
hPa
795 - 1080
795 - 1080
795 - 1080
795 - 1080
Ambient mechanical conditions
Protection type
(
IEC/EN 60529, EN50178, VBG 4)
IP65
IP20
IP20
IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm
Hz
10 - 57
10 - 57
10 - 57
10 - 57
Constant acceleration, 2 g
Hz
57 - 150
57 - 150
57 - 150
57 - 150
Mechanical shock resistance (IEC/EN
60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18
18
18
18
Drop to IEC/EN 60068-2-31
Drop
height
mm 50
50
50
50
Free fall, packaged (IEC/EN 60068-2-32)
m
1
1
1
1
Mounting position
Vertical or horizontal
