Control relays, multi-function display
Basic devices, expansion devices
2010
CA08103002Z-EN
www.eaton.com...DC...
...DC...Basicdevices,expansiondevices
EASY406…-DC-ME EASY411-DC-ME EASY512-DC-… EASY7..-DC-… EASY8..-DC-…
Analog inputs
Number
2
6
2 (
I7, I8)
4 (
I7, I8, I11, I12)
4 (
I7, I8, I11, I12)
Potential isolation
From power supply
No
No
No
No
No
From the digital inputs
No
No
No
No
No
From the outputs
No
No
Yes
Yes
Yes
From PC interface, memory card,
easyNet, easyLink
Yes
Yes
No
No
Yes
Input type
DC voltage
DC voltage
DC voltage
DC voltage
DC voltage
Signal range
V DC 0 - 10
0 - 10
0 - 10
0 - 10
0 - 10
Resolution, analog
V
–
–
0.01
0.01
0.01
Resolution, digital
V
–
–
0.01
0.01
0.01
Resolution
Bit
10 (
value 0 - 1023)
Input impedance
kΩ
11.2
11.2
11.2
11.2
11.2
Accuracy of actual value
Two EASY devices
%
± 3
± 3
± 3
± 3
± 3
Within a single device
%
< ± 3 %
< ± 3 %
± 2, (I7, I8, I11, I12)
± 0.12 V
± 2, (I7, I8, I11, I12)
± 0.12 V
± 2, (I7, I8, I11, I12)
± 0.12 V
Conversion time analog/digital
ms
800
800
Input delay ON: 20; input delay OFF: every
cycle time
Each CPU
cycle
Input current
mA
< 1
< 1
< 1
< 1
< 1
Cable length shielded
m
< 10
< 10
< 30
< 30
< 30
Analog outputs
Number
1
2
–
–
1
Potential isolation
From power supply
No
No
No
No
No
From the digital inputs
No
No
No
No
No
From the digital outputs
No
No
No
No
Yes
easyLink
Yes
Yes
No
No
Yes
Output type
DC voltage
DC voltage
–
–
DC voltage
Signal range
Signal range min. voltage
V
0
0
–
–
0
Signal range max. voltage
V
10
10
–
–
10
Max. output current
A
0.01
0.01
–
–
0.01
Load resistance
1
kΩ
1
kΩ
–
–
1
kΩ
Overload and short-circuit protection
Yes
Yes
–
–
Yes
Resolution, analog
V DC 0.01
0.01
–
–
0.01
Resolution, digital
Bit
10 (
value 0 - 1023)
10 (
value 0 - 1023)
–
–
10, (
value:
0 – 1023)
Recovery time
μs
–
–
–
–
100
Accuracy
-25
°C - 55 °C
% 2
2
–
–
2
25
C
% 1
1
–
–
1
Conversion time analog/digital
ms
200
200
Input delay ON: 20; input delay OFF:
every cycle time
Each CPU
cycle
Network easyNet
Stations
Number –
–
–
–
Max. 8
Data transfer rate/distance
–
–
–
–
1000
Kbit/s, 6 m
500
Kbit/s, 25 m
250
Kbit/s, 60 m
125
Kbit/s, 125 m
50
Kbit/s, 300 m
20
Kbit/s, 700 m
10
Kbit/s, 1000 m
Potential isolation
Of the 2 additional inputs
–
–
–
–
Yes
Potential isolation
–
–
–
–
Yes
Electrical isolation between inputs and
internal power supply
–
–
–
–
Yes
Potential isolation
–
–
–
–
Yes
Bus termination (first and last station)
–
–
–
–
Yes
Terminal type
–
–
–
–
RJ45, 8 pole
Notes
For additional technical data EASY5… and EASY7…￫AWB2528-1508D, EASY8…￫AWB2528-1423D
