Control relays, multi-function display
Basic devices, expansion devices
2010
CA08103002Z-EN
www.eaton.com...AC...
12/35
...AC...Basicdevices,expansiondevices
EASY512-AC-R..
EASY618-AC-RE
EASY719-AC-RC.
EASY819-AC-RC.
Power supply
Rated operational voltage
U
e
V
100/110/115/120/230/240
AC (+10/-15 %)
Permissible range
V AC 85…264
85…264
85…264
85…264
Frequency
Hz
50/60 (
± 5%)
50/60 (
± 5%)
50/60 (
± 5%)
50/60 (
± 5%)
Input current
At 115/120 V AC 60 Hz
mA
Normally 40
Normally 70
Normally 70
Normally 70
At 230/240 V AC 50 Hz
mA
Normally 20
Normally 35
Normally 35
Normally 35
Voltage dips (IEC/EN 61131-2)
ms
20
20
20
20
Heat dissipation
At 115/120 V AC
VA
Normally 5
Normally 10
Normally 10
Normally 10
At 115/230 V AC
VA
Normally 5
Normally 10
Normally 10
Normally 10
Digital inputs 115/230 V AC
Number
8
12
12
12
Status display
LCD display (if provided)
Potential isolation
From power supply
No
No
No
No
Between digital inputs
No
No
No
No
From the outputs
Yes
Yes
Yes
Yes
Potential isolation
–
–
–
Yes
Rated voltage L (sinusoidal)
On signal ”0”
V AC 0 - 40
0 - 40
0 - 40
0 - 40
On signal ”1”
V AC 79 - 264
79 - 264
79 - 264
79 - 264
Rated frequency
Hz
50 - 60
50 - 60
50 - 60
50 - 60
Input current on signal "1"
R1 to R12
mA
12
x 0.25 (at 115 V AC,
60
Hz)12 x 0.5
(
at 230 V AC, 50 Hz)
I1 to I6
mA
6
x 0.25 (at 115 V AC,
60
Hz)6 x 0.5
(
at 230 V AC, 50 Hz)
6
x 0.25 (at 115 V AC,
60
Hz)6 x 0.5
(
at 230 V AC, 50 Hz)
6
x 0.25 (at 115 V AC,
60
Hz)6 x 0.5
(
at 230 V AC, 50 Hz)
I7, I8
mA
2
x 4 (at 115 V AC,
60
Hz)2 x 6
(
at 230 V AC, 50 Hz)
2
x 4 (at 115 V AC,
60
Hz)2 x 6
(
at 230 V AC, 50 Hz)
2
x 4 (at 115 V AC,
60
Hz)2 x 6
(
at 230 V AC, 50 Hz)
I9 to I12
mA
4
x 0.25 (at 115 V AC,
60
Hz)4 x 0.5
(
at 230 V AC, 50 Hz)
4
x 0.25 (at 115 V AC,
60
Hz)4 x 0.5
(
at 230 V AC, 50 Hz)
Delay time
Delay time (0 - 1/1 - 0) I1 - I6, I9 - I12,
R1 - R12
Debounce ON, 50/60 Hz
ms
80
⁄66⅔
80
⁄66⅔
80
⁄66⅔
80
⁄66⅔
Debounce OFF, 50/60 Hz
ms
20
⁄16⅔
20
⁄16⅔
20
⁄16⅔
20
⁄16⅔
Delay time I7, I8 (1 - 0)
Debounce ON, 50/60 Hz
ms
160
⁄150
80
⁄66⅔
80
⁄66⅔
120
⁄100
Debounce OFF, 50/60 Hz
ms
100
⁄100
20
⁄16⅔
20
⁄16⅔
40
⁄33⅔
Delay time I7, I8 (0 - 1)
Debounce ON, 50/60 Hz
ms
80
⁄66⅔
80
⁄66⅔
80
⁄66⅔
80
⁄66⅔
Debounce OFF, 50/60 Hz
ms
20
⁄16⅔
20
⁄16⅔
20
⁄16⅔
20
⁄16⅔
Max. admissible cable length (per input)
R1 to R12
m
–
Normally 40
–
–
I1 to I6
m
Normally 40
Normally 40
Normally 40
Normally 60
I7, I8
m
Normally 100
Normally 100
Normally 100
Normally 100
I9 to I12
m
–
Normally 40
Normally 40
Normally 60
Relay outputs
￫See technical data, relay outputs
Notes
For additional technical data EASY5… and EASY7…￫AWB2528-1508D, EASY8…￫AWB2528-1423D
