Control relays
Basic devices, expansion devices
2010
CA08103002Z-EN
www.eaton.com...
...Basicdevices,expansion devices
EASY200-EASY
EASY202-RE
EASY4…-DC-…E
EASY6...
EASY8..-…
EASY512-…
EASY7…
General
Standards
EN 55011, EN 55022, IEC/EN 61000-4, IEC 60068-2-6, IEC 60068-2-27
Dimensions (W x H x D)
mm 35.5 x 90 x 58
(2
space units)
71.5
x 90 x 58
(4
space units)
107.5
x 90 x 58
(6
space units)
107.5
x 90 x 72
(6
space units)
Weight
kg
0.07
0.2
0.3
0.3
Mounting
Top-hat rail IEC/EN 60715, 35 mm or screw fixing using fixing brackets ZB4-101-GF1
(
accessories).
Terminal capacity
Solid
mm
2
0.2 - 4 (
AWG 22 - 12)
Flexible with ferrule
mm
2
0.2 - 2.5 (
AWG 22 - 12)
Flat-blade screwdriver
mm 3.5 x 0.8
Max. tightening torque
Nm 0.6
Ambient climatic conditions
Operating ambient temperature
°C
-25…55,
low temperatures to IEC 60068-2-1, high temperatures to IEC 60068-2-2
Condensation
Prevent condensation by means of suitable measures
LCD display (clearly legible)
°C
0 - 55
0 - 55
0 - 55
0 - 55
Storage
°C
-40 - 70
-40 - 70
-40 - 70
-40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30)
% 5 - 95
5 - 95
5 - 95
5 - 95
Air pressure (in operation)
hPa
795 - 1080
795 - 1080
795 - 1080
795 - 1080
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4)
IP20
IP20
IP20
IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm
Hz
10 - 57
10 - 57
10 - 57
10 - 57
Constant acceleration, 2 g
Hz
57 - 150
57 - 150
57 - 150
57 - 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18
18
18
18
Drop to IEC/EN 60068-2-31
Drop height
mm 50
50
50
50
Free fall, packaged (IEC/EN 60068-2-32)
m
1
1
1
1
Mounting position
Vertical or horizontal
Electromagnetic compatibility (EMC)
Overvoltage category/pollution degree
II/2
II/2
II/2
II/2
Electrostatic discharge (ESD), to IEC EN 61000-4-2
Air discharge
kV
8
8
8
8
Contact discharge
kV
6
6
6
6
Electromagnetic fields (RFI), to IEC EN 61000-4-2
V/m 10
10
10
10
Radio interference suppression
EN 55011 Class B, EN 55022 Class B
Burst to IEC/EN 61000-4-4
Supply cables
kV
2
2
2
2
Signal cables
kV
2
2
2
2
Power pulses (surge), to IEC/EN 61000-4-5
kV
2 (
supply cables, symmetrical, EASY…AC)
Power pulses (surge), to IEC/EN 61000-4-5
kV
0.5 (
supply cables, symmetrical, EASY…DC)
Radiated RFI, to IEC/EN 61000-4-6
V
10
10
10
10
Insulation resistance
Clearance in air and creepage distances
EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance
EN 50178
EN 50178
EN 50178
EN 50178
Back-up/accuracy of the real-time clock
Back-up time
–
–
1)
–
1)
1)
Accuracy of the real-time clock at 55 °C
s/day
–
–
Normally±5
(
±0.5h⁄Year)
–
Normally±5
(
±0.5h⁄Year)
Normally ± 5
(
± 0.5 h⁄Year)
Repetition accuracy of timing relays
Accuracy of timing relay (of value)
% –
–
± 1
± 0.02
± 0.02
Resolu-
tion
Range “S”
ms
–
–
10
10
5
Range “M:S”
s
–
–
1
1
1
Range “H:M”
min
–
–
1
1
Retentive memory
Write cycles of the retentive memory (minimum)
–
–
1000000
(106)
1000000
(106)
10000000 (10
10
)
(
read/write cycles)
Notes
For additional technical data EASY5…and EASY7…￫AWB2528-1508D, EASY8…￫AWB2528-1423D
1)
①
Back-up time (hours)
②
Service life (years)
a
b
180
200
160
140
120
100
80
60
40
20
0
0
2 4
6
8
10
20
12 14
1 3
5
7
9
11 13
55
°C
25
°C
15 17 19
16 18
Technical data
