Multi-function display
Expansion devices
2010 CA08103002Z-EN
MFD-Titan 12/25
MFD-TitanExpansiondevices
Inputs Outputs Supply
voltage
Part no.
Article no.
Price
See
price list
Std. pack Information relevant for export to North America
Digital Relay
10 A (UL)
Transistor
I/O expansions
Can be used through easyLink
12 6 – 100 - 240 V
AC
EASY618-AC-RE
212314
1 off Product Standards IEC/EN see Technical Data;
UL 508; CSA C22.2 No. 142-
M1987; CSA C22.2 No. 213-
M1987; CE marking
UL File No. E135462
UL CCN NRAQ, NRAQ7
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
12 – 8 24 V DC EASY620-DC-TE
212313
12 6 – 24 V DC EASY618-DC-RE
232112
Product Standards IEC/EN see Technical Data;
UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ, NRAQ7
CSA File No. 012528
CSA Class No. 2252-01
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
– 2 – 24 V DC EASY202-RE 1)
232186
6 4 – 24 V DC EASY410-DC-RE
114293
NA Certification Request filed
for UL and CSA
Degree of Protection IEC: IP20,
UL/CSA Type: - 6 – 4 24 V DC EASY410-DC-TE
114294
Coupling module
Can be used through easyLink
For remote
connection of
a digital I/O
expansion up
to 30 m.
EASY200-EASY
212315
1 off Product Standards IEC/EN see Technical Data;
UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ, NRAQ7
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Inputs Outputs Supply
voltage
Part no.
Article no.
Price
See
price list
Std. pack
Digital / Analog Of which
usable as
digital
Relay 10 A
(UL)
Transistor Analog
I/O expansions
Can be used through easyLink
1 / 2 2) 2 – 2 1 24 V DC EASY406-DC-ME
114295
1 off
1 / 6 3) 2 – 2 2 24 V DC EASY411-DC-ME
116567
1 off
Notes 1) Not for use in combination with basic unit EASY719-DA-...
Cannot be used on the EASY200‐EASY coupling module
2) 2 × 0 - 10 V, 2 × 0 - 20 mA, 2 × RTD (2/3-wire connection);
any combination
Voltage inputs (0–10 V) can optionally be used as digital inputs
3) 2 x 0 - 10 V, 2 x 0 - 20 mA, 2 x Pt100 (2/3 wire connection);
Voltage inputs (0 –10 V) can optionally be used as digital inputs
Information relevant for export to North America
NA Certification Request filed for UL and CSA
Degree of Protection IEC: IP20,
UL/CSA Type: -
