12/22 Multi-function display
Display/operating units, CPU, communication modules
2010 CA08103002Z-EN
MFD-Titan
Ordering
MFD-TitanDisplay/operatingunits,CPU,communicationmodules
Supply
voltage
Description Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Display/keypad
Monochrome display 132 × 64 pixels with switchable backlight
IP65, removable silver front frame
With keypad, with Moeller company
logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B
265251
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, in combination
with MFD-XM-80: UL/CSA
Type 4X
With keypad, without Moeller company
logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B-X
284905
1 off
Without keypad, with Moeller
company logotype NEMA 4x
MFD-80
265250
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, UL/CSA Type 4X
Without keypad,
without Moeller company logotype
NEMA 4x
MFD-80-X
284904
1 off
Power supply unit/CPU module
Can be combined with display and control unit MFD-80-..
and I/O module; expandable: Digital and analog inputs/outputs
and bus systems
AS-Interface, CANopen, PROFIBUS-DP, DeviceNet;
bus system easyNet optional on-board IP20
Spring-loaded terminals
Supply
voltage
100 - 240V AC Program and
screen memory,
with easyNet
MFD-AC-CP8-NT
274092
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
100 - 240V AC Program and
screen memory,
without easyNet
MFD-AC-CP8-ME
274091
24 V DC Program and
screen memory,
without easyNet
MFD-CP8-ME
267164
24 V DC Program and
screen memory,
with easyNet
MFD-CP8-NT
265253
24 V DC Dual program and
screen memory as
MFD-...-CP8...,
without easyNet
MFD-CP10-ME 1)
133801
1 off
24 V DC Dual program and
screen memory as
MFD-...-CP8...,
with easyNet
MFD-CP10-NT 1)
133800
1 off
1) Note 1) For availability please inquire
