61 / 253
Control relays
Accessories
2010
CA08103002Z-EN
www.eaton.com800
12/19
800Accessories
MFD-Titan
Description
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to North America
Ballast
To increase the AC input current
6
channels, cable length up to
100
m
EASY256-HCI
231168
1
off
Product Standards IEC/EN see Technical Data;
UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No.
E135462
UL CCN
NRAQ
CSA File No.
012528
CSA Class No.
2252-01
NA Certification
UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
PROFIBUS-DP data cable
Twisted pair, without plug, 2-core,
2
x 0.64 mm²
(
only suitable for fixed wiring)
100
m
ZB4-900-KB1
206983
100
m
PROFIBUS-DP bus connector plug
Pins, 9 pole
Cable entry, angled 90°
ZB4-209-DS2
206982
1
off
Metallized insulated housing
Maximum transfer rate 12 Mbits/s
Integrated plug, accessible from
outside, for bus terminating
resistors
Terminal block for two cable
entries, with straight or 90° angled
cable entry, as required
ZB4-209-DS3
217820
1
off
Connection plug
Bus connector plug between
base unit and expansion unit/bus
module
EASY-LINK-DS
221607
1
off
UL/CSA certification not required
Fixing bracket
For screw fixing to mounting plate
3
fixing brackets
per easy400, 500, 600, 700, 800,
EC4P, ES4P
2
fixing brackets per easy200
3
fixing brackets per
MFD...-CP8/CP10-…
ZB4-101-GF1
061360
9
off
UL/CSA certification not required
Telescopic clip
With 35 mm top-hat rail to
IEC/EN 60715 for mounting
depth compensation when rear
mounting in CI-K… enclosures
and cabinets.
Stepless adjustment via scale
from 75 – 115 mm.
Screw and snap fastening
M22-TA
226161
1
off
Product Standards IEC/EN 60947-5; UL 508; CSA-
C22.2 No. 14-05; CSA-C22.2 No.
94-91;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Top-hat rail adapter for inspection flap window
12
mm x 66 mm x 82 mm
Mounting on hinged inspection
window, for front fitting of devices.
Complete set, consisting of
2
brackets and 4 screws
SKF-HA
233782
1
off
UL/CSA certification not required
Inspection window
130
mm x 77 mm x 25 mm (6 space
units)
For use with EASY700, EASY800,
EC4P, ES4P
SKF-FF6
233781
1
off
UL/CSA certification not required
HPL12019EN
