Multi-function display

Display/operating unit, power supply unit/CPU module

MFD-Titan

12/21

MFD-TitanDisplay/operatingunit,power supplyunit/CPUmodule

MFD-Titan

The multi-function display MFD-Titan

can be used in the following

combinations:

Power supply unit/CPU

Power supply unit/CPU + I/O modules

Power supply unit/CPU + display and

operating unit

Power supply unit/CPU + display and

operating unit + I/O modules

￫Page 12/22

I/O modules

1

24

V DC

100 - 240

V AC

12

digital inputs

4

usable as analog inputs

(

DC versions)

4

relay outputs (max. 10 A,UL)

or 4 transistor outputs

1

analog output,

optional on DC versions

Spring-loaded terminals

￫Page 12/24

I/O modules with temperature

measuring

1

24

V DC

6

digital inputs

2

of which usable as analog inputs

2

Pt 100 or 2 Ni1000 RTD inputs

4

transistor outputs

1

Analog output, optional

Spring-loaded terminals

￫Page 12/24

Power supply unit/CPU module

1

24

V DC

100 - 240

V AC

Bus system easyNet optionally

on-board

￫Page 12/22

Display/keypad

1

24

V DC

Monochrome display

132

× 64 pixels

With or without keypad

Custom laser labeling possible

￫Page 12/16

Ethernet gateway

EASY209-SE

2

24

V DC

Serial interface, PSU/CPU module to

Ethernet

￫Page 12/16

Bus modules

EASY204-DP

3

PROFIBUS DP connection as slave,

24

V DC

￫Page 12/16

EASY221-CO

5

CANopen connection, 24 V DC

￫Page 12/16

EASY205-ASI

4

AS-Interface connection as slave

￫Page 12/16

EASY222-DN

6

DeviceNet connection, 24 V DC

￫Page 12/16

Output expansion

EASY202-RE

7

2

relay outputs (max. 10 A, UL)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

I/O expansions

EASY406-DC-ME

8

24

V DC

1

digital input

2

analog inputs

(2

× 0–10 V, 2 × 0–20 mA, 2 × RTD);

any combination

Voltage inputs (0–10 V) can optionally

be used as digital inputs

2

transistor outputs

1

analog output (0 - 10 V)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY411-DC-ME

8

24

V DC

1

digital input

6

analog inputs

(2

x 0 - 10 V, 2 x 0 - 20 mA, 2 x Pt100);

Voltage inputs (0–10 V) can optionally

be used as digital inputs

2

transistor outputs/

2

Analog outputs (0 - 10 V)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY6...

9

24

V DC

12

digital inputs

6

relay outputs (max. 10 A,UL)

or 8 transistor outputs

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY410...

10

24

V DC

6

digital inputs

4

relay outputs (max. 10 A,UL)

or 4 transistor outputs

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

Coupling module

EASY200-EASY

11

For remote connection of a digital

I/O expansion through two-pole

connection cable (max. 30 m);

e.g. NYM 3 × 1.5 mm²

￫Page 12/15

Compact PLCControl

EC4P

12

￫Page 14/64

Safety control relays

Safety

ES4P

13

￫Page 13/5

Control relays800

EASY8…

14

￫Page 12/14
