12/18 Control relays
Accessories
2010 CA08103002Z-EN
800
800Accessories
800Accessories
Description For use with Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Network connection cables
Length: 0.3 m easyNet EASY-NT-30
256283
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Length: 0.8 m easyNet EASY-NT-80
256284
Length: 1.5 m easyNet EASY-NT-150
256285
Bus termination resistor
8 pole, RJ45, 124 Ω
Connection to PIN 1 and
PIN 2
easyNet EASY-NT-R
256281
2 off
Data cable
4 x 0.14 mm², twisted pair,
AWG 26
Length: 100 m
easyNet EASY-NT-CAB
256286
1 off UL File No. E135462
UL CCN NRAQ
NA Certification UL Listed
Degree of Protection IEC: IP 20, UL/CSA Type: -
Bus connector plug
8 pole, RJ45 easyNet EASY-NT-RJ45
256280
10 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Crimping tool
For RJ45 plug EASY-NT-CAB
EASY-NT-RJ45
EASY-RJ45-TOOL
256282
1 off
Point-to-point connection cable
Serial interface for
connecting MFD-…-CP8/
CP10... to easy800 or
MFD-…-CP8/CP10..., 5 m,
can be cut to length
MFD-800-CAB5
266041
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Switched-mode power supply units
Primary-switched mode, stabilized
Rated input voltage:
50/60 Hz: 100 - 240 V
Rated output voltage:
24 V/12 V DC
Rated output current:
0.35 A/20 mA
EASY200-POW
229424
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Rated input voltage:
50/60 Hz: 100 - 240 V AC
Rated output voltage (residual ripple): 24 V
DC (± 3 %)
Rated output current:
1.25 A
EASY400-POW
212319
1 off
EASY430-POW
110940
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 107.1-01;
CE marking
UL File No. E300415
UL CCN NMTR, NMTR7
CSA File No. UL report applies to both
US and Canada
CSA Class No. 3211-87, 3211-07
NA Certification UL Listed, certified by UL
for use in Canada
Degree of Protection IEC: IP20, UL/CSA Type: -
Rated input voltage:
50/60 Hz: 100 - 240 V AC
Rated output voltage (residual ripple): 24 V
DC (± 3 %)
Rated output current: 2.5 A
EASY500-POW
110941
1 off
Rated input voltage:
50/60 Hz: 100 - 240 V AC
Rated output voltage (residual ripple): 24 V
DC (± 3 %)
Rated output current: 4.2 A
EASY600-POW
262399
1 off
