Control relays

800

12/13

800

Basic device

800

1

Expandable: Digital and analog inputs/

outputs and bus systems AS-Interface,

CANopen, PROFIBUS-DP, DeviceNet

Bus system easyNet on board

24

V DC = easy...DC...

100 - 240

V AC = easy...AC...

12

digital inputs

4

usable as analog inputs (DC ver-

sions)

6

relay outputs (max. 10 A, UL) or

8

transistor outputs

1

analog output, optional on DC

versions

Display and keypad optional

Bolt-on and top-hat rail mounting

Screw terminals

Technical overview

￫Page 12/14

Remote text display

Consists of:

Display/operating unit MFD-80(-B)

2

Power supply/communication

module

2

Including connection cable

(5

m, can be cut to length) for

easy800

24

V DC = MFD-CP4-800

100 - 240

V AC = MFD-AC-CP4-800

Spring-loaded terminals

￫Page 12/16

Ethernet gateway

EASY209-SE

3

24

V DC

Serial interface easyRelay to

Ethernet

￫Page 12/16

Bus modules

EASY204-DP4

4

PROFIBUS DP connection as slave,

24

V DC

￫Page 12/16

EASY205-ASI

5

AS-Interface connection as slave

￫Page 12/16

EASY221-CO

6

CANopen connection, 24 V DC

￫Page 12/16

EASY222-DN

7

DeviceNet connection, 24 V DC

￫Page 12/16

Output expansion

EASY202-RE

8

2

relay outputs (max. 10 A, UL)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

I/O expansions

EASY406-DC-ME

9

24

V DC

1

digital input

2

analog inputs (2 × 0–10 V, 2 × 0 – 20

mA, or 2 × x Pt100; voltage inputs can

be combined in any arrangement

Voltage inputs (0 – 10 V) can

optionally be used as digital inputs

2

transistor outputs

1

analog output (0 - 10 V)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY411-DC-ME

9

24

V DC

1

digital input

6

analog inputs (2 × 0–10 V, 2 × 0–20

mA and 2 × Pt100; voltage inputs

(0–10

V) can optionally be used as

digital inputs

2

transistor outputs/

2

analog outputs (0–10 V)

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY6...

10

24

V DC

12

digital inputs

6

relay outputs (max. 10 A, UL) or

8

transistor outputs

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

EASY410...

12

24

V DC

6

digital inputs

4

relay outputs (max. 10 A, UL) or

4

transistor outputs

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

Coupling module

EASY200-EASY

11

For remote connection of a digital

I/O expansion through two-pole

connection cable (max. 30 m);

e.g. NYM 3 × 1.5 mm²

Bolt-on and top-hat rail mounting

Screw terminals

￫Page 12/15

Compact PLCControl

EC4P

13

￫Page 14/64

Safety control relays

Safety

ES4P

14

￫Page 13/5

Multi-function display

MFD-Titan

15

￫Page 12/22
