Control relays
Accessories
2010 CA08103002Z-EN
500/700 12/9
Accessories500/700
Supply
voltage
Description Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Remote text display
Display/keypad
Monochrome display 132 × 64 pixels with switchable
backlight
IP65, removable silver front frame
With keypad, with Moeller company logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B
265251
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, in combination
with MFD-XM-80: UL/CSA
Type 4X
With keypad, without Moeller company
logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B-X
284905
Without keypad, with Moeller company
logotype
MFD-80
265250
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, UL/CSA Type 4X
Without keypad,
without Moeller company logotype
NEMA 4x
MFD-80-X
284904
Power supply unit/communication modules
IP20, can be combined with display/operating unit MFD-80... as
remote text display
24 V DC With connection cable
(5 m, can be cut to length)
MFD-CP4-500
274094
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
100 - 240 V AC With connection cable
(5 m, can be cut to length)
MFD-AC-CP4-500
286823
24 V DC Without connection cable MFD-CP4
280888
100 - 240 V AC Without connection cable MFD-AC-CP4
286822
Programming software
Menu selection in 13 languages
Operating systems: Windows 2000 SP4,
Windows XP SP3,
Windows Vista (32 Bit), Windows 7 (32 Bit)
EASY-SOFT-BASIC
284545
1 off UL/CSA certification not required
EASY-SOFT-PRO
266040
Programming cable
SUB-D, 9 pole, serial, 2 m EASY-PC-CAB
202409
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
USB, 2 m EASY-USB-CAB
107926
1 off
Connecting cables
For connecting the MFD(-AC)-CP4 or
EASY209-SE with easy500/easy700,
5 m, can be cut to length
MFD-CP4-500-
CAB5
280886
1 off
Memory cards
32-kB module EASY-M-32K
270884
1 off
Manuals
Deutsch AWB2528-1508D
278499
1 off
English AWB2528-1508GB
278500
1 off
