Control relays
Basic devices
2010
CA08103002Z-EN
www.eaton.com500/700
12/7
500/700Basicdevices
Inputs
Outputs
Other features
Supply
voltage
Part no.
Article no.
Price
See price
list
Std. pack
Digital
Of which
can be
used as
analog
Relays10A
(
UL)
Transistor Display +
keypad
Real-time
clock
700
Expandable: Digital inputs/outputs and bus systems AS-Interface, CANopen, PROFIBUS-DP, DeviceNet
12
4
6
–
√
√
24
V AC
EASY719-AB-RC
274113
1
off
12
4
6
–
–
√
24
V AC
EASY719-AB-RCX
274114
12
–
6
–
√
√
100 - 240
V AC
EASY719-AC-RC
274115
12
–
6
–
–
√
100 - 240
V AC
EASY719-AC-RCX
274116
12
4
6
–
√
√
12
V DC
EASY719-DA-RC
274117
12
4
6
–
–
√
12
V DC
EASY719-DA-RCX
274118
12
4
6
–
√
√
24
V DC
EASY719-DC-RC
274119
12
4
6
–
–
√
24
V DC
EASY719-DC-RCX
274120
12
4
–
8
√
√
24
V DC
EASY721-DC-TC
274121
12
4
–
8
–
√
24
V DC
EASY721-DC-TCX
274122
Customized inscription, user program
•
Customized inscription of easy control relay trough labeling software Labeleditor or
•
Supply of easy control relay programmed with user program
EASY-COMBINATION-*
1)
257823
1
off
Notes
Procedure and ordering example for Labeleditor inscription software
Individually inscribe your device in 4 stages:
–
Download the inscription software:
www.moeller.net/support,
keyword: “Labeleditor”
–
Creation of label template (menu-guided in the software)
–
Send the label template to the factory by email.
The email address is automatically set for the selected product by the
program.
When your template is sent, the Labeleditor issues a file name such
as “EASY_12345.zip”.
This file name is part of the article to be ordered (see Ordering
examples).
–
Send order to the Eaton office or the electrical wholesalers.
Ordering example
EASY719-DC-RC with “Company logo”:
1
x EASY-COMBINATION-*
1
x EASY719-DC-RC
1
x the file name “EASY_xxxxx.zip” issued by the Labeleditor
Information relevant for export to North America
Product Standards
IEC/EN see Technical Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No.
E135462
UL CCN
NRAQ
CSA File No.
012528
CSA Class No.
2252-01
+ 2258-02
NA Certification
UL Listed, CSA certified
Degree of Protection
IEC: IP20, UL/CSA Type: -
1)
UL/CSA certification not required
Accessories
Page
1
Ethernet gateway
￫Page 12/16
2
Connection cable
￫Page 12/27
3
Power supply unit/communication module
￫Page 12/23
4
Display/keypad
￫Page 12/16
5
Programming software
￫Page 12/9
6
PC programming cable
￫Page 12/9
7
Switched-mode power supply unit
￫Page 12/10
8
Memory card
￫Page 12/9
9
Inputs/outputs expansion
￫Page 12/15
10
output expansion, bus module, coupling module
￫Page 12/16
ESC
OK
DEL
ALT
easy 700
Power
1
4
3
2
5
9
9
10
2, 6
8
7
2
6
6
Power
Power
