Control relays, multi-function display
Technical overview
2010 CA08103002Z-EN
12/3
Technical overview
Functions Technicaloverview easy500/700 easy800 MFD-...CP8...
Counter functions Counter relay
(up, down counting)
16 (0 to 32000) 32 ( g231 ) 32 ( g231)
Frequency counters 2 (max. 1 kHz) 4 (max. 5 kHz) 4 (max. 3 kHz)
High-Speed counter 2 (max. 1 kHz) 4 (max. 5 kHz) 4 (max. 3 kHz)
Incremental counters – 2 (max. 3 kHz) 2 (max. 3 kHz)
Hour meter 4 (operating hours value is stored super-retentively (e.g also with program change)
Time functions Weekly timer (4 channels per timer,
each channel offers one On/Off time)
8 32 32
Year time switch 8 32
Set cycle time – 1 1
Timing relay 16
(0.01 s … 99 h 59 min)
32 (0.005 s … 2³² min), On-delayed and/or off-delayed
(optionally random switching), pulse shaping, flashing
Program sequencing functions Jump 8 32 32
Conditional jump – 32 32
Master reset 3 32 32
Maths functions Analog value comparator 16 32 32
Arithmetic – 32 (ADD, SUB, MUL, DIV) 32 (ADD, SUB, MUL, DIV)
PID controller – 32 32
PT1 signal smoothing filter – 32 32
Value scaling – 32 32
Numerical converter – 32 32
Pulse output – 2 –
Pulse width modulation – 2 2
Value limit – 32 32
Memory functions Block comparison – 32 32
Block transfer – 32 32
Boolean operation – 32 (AND, OR, NOT) 32 (AND, OR, NOT)
Comparator 16 32 32
Data function block – 32 32
Data multiplexer – 32 –
Shift register – 32 32
Table function – 32 32
Communication functions Get value from the NET – 32 32
Put value on the NET – 32 32
Bit output via NET – 32 32
Bit input via NET – 32 32
Diagnostic alarm – 9 9
Serial protocol – 32 –
Synchronize clock via NET – 1 1
Text functions Text display
(can be edited via software)
16 x (4 x 12 characters) 32 x (4 x 16 characters) Yes
Static text Yes
Message text Yes
Screen menu Yes
Running text Yes
Rolling text Yes
Value entry functions Date and time information Yes
Year time switch entry Yes
Latching pushbutton Yes
Button field Yes
Timing relay value entry Yes Yes Yes
Value entry Yes
Week clock input Yes
Enter counter value/reference value/OT Yes Yes Yes
Value display functions Bit display Yes
Message bitmap Yes
Bargraph Yes
Numerical value Yes
Timing relay value display Yes
Actual values Yes Yes Yes
Date and time Yes Yes Yes
