12/16 Control relays
Expansion units, accessories
2010 CA08103002Z-EN
800
800Expansionunits,accessories
Description Supply
voltage
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Bus modules
Can be used through easyLink
AS-Interface Slave
4 inputs, 4 outputs,
4 parameter bits
Addresses
available
0 to 31
– EASY205-ASI
221598
1 off Product Standards IEC/EN see Technical
Data;
UL 508; CE marking;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987
UL File No. E135462
UL CCN NRAQ, NRAQ7
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
PROFIBUS-
DP
Slave
Addresses
available
1 to 126
24 V DC EASY204-DP
212316
CANopen Addresses
available
1 to 127
24 V DC EASY221-CO
233539
DeviceNet Addresses
available
0 to 63
24 V DC EASY222-DN
233540
Ethernet gateway
Serial interface easyRelay or
MFD-...CP8/CP10... to Ethernet,
for connecting to easyOPC server,
easySoft, or easyCom
24 V DC EASY209-SE
101520
1 off
Remote text display
Display/keypad
Monochrome display 132 × 64 pixels with switchable backlight
IP65, removable silver front frame
With keypad, with Moeller company logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B
265251
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, in combination
with MFD-XM-80: UL/CSA
Type 4X
With keypad, without Moeller company
logotype
NEMA 4x in conjunction with MFD-XM-80
protective diaphragm￫12/29
MFD-80-B-X
284905
1 off
Without keypad, with Moeller company
logotype
MFD-80
265250
1 off Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP65, UL/CSA Type 4X
Without keypad,
without Moeller company logotype
NEMA 4x
MFD-80-X
284904
1 off
Power supply unit/communication modules
IP20, can be combined with display/operating unit MFD-80... as
remote text display
Product Standards IEC/EN see Technical
Data; UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
With connection cable
(5 m, can be cut to length)
24 V DC MFD-CP4-800
274095
1 off
With connection cable
(5 m, can be cut to length)
100 - 240 V AC MFD-AC-CP4-800
286824
Without connection cable 24 V DC MFD-CP4
280888
Without connection cable 100 - 240 V AC MFD-AC-CP4
286822
