Control relays, multi-function display
I/O modules
2010 CA08103002Z-EN
MFD-(AC)-R..., MFD-T... 12/39
MFD-(AC)-R...,MFD-T...I/Omodules
MFD-(AC)-R...,MFD-TI/Omodules
MFD-R16
MFD-RA17
MFD-AC-R16 MFD-T16
MFD-TA17
MFD-T.P..
General
Standards EN 61000-6-1/-2/-3/-4,
IEC/EN 61000-4,
IEC 60068-2-6,
IEC 60068-2-27
EN 61000-6-1/-2/-3/-4,
IEC/EN 61000-4,
IEC 60068-2-6,
IEC 60068-2-27
EN 61000-6-1/-2/-3/-4,
IEC/EN 61000-4,
IEC 60068-2-6,
IEC 60068-2-27
EN 61000-6-1/-2/-3/-4,
IEC 60068-2-6, IEC
60068-2-27
Dimensions (W x H x D) mm 89 x 90 x 44 89 x 90 x 44 89 x 90 x 25 (built-in) 89 x 90 x 25 (built-in)
Weight kg 0.15 0.15 0.14 0.14
Mounting Fitted into the power supply unit.
Terminal capacity
Solid mm2 0.2⁄4 (AWG 24 - 12) 0.2⁄4 (AWG 24 - 12) 0.2⁄4 (AWG 24 - 12) 0.2⁄4 (AWG 24 - 12)
Flexible with ferrule mm2 0.2⁄2.5 (AWG 24 - 12) 0.2⁄2.5 (AWG 24 - 12) 0.2⁄2.5 (AWG 24 - 12) 0.2⁄2.5 (AWG 24 - 12)
Flat-blade screwdriver mm 3.5 x 0.6 3.5 x 0.6 3.5 x 0.6 3.5 x 0.6
Power supply
Solid mm2 – – – –
Flexible with ferrule mm2 – – – –
Flat-blade screwdriver mm – – – –
Data cable
Solid mm2 0.08⁄2.5 (AWG 28 - 12) 0.08⁄2.5 (AWG 28 - 12) 0.08⁄2.5 (AWG 28 - 12) 0.08⁄2.5 (AWG 28 - 12)
Flexible with ferrule mm2 0.08⁄1.5 (AWG 28 - 12) 0.08⁄1.5 (AWG 28 - 12) 0.08⁄1.5 (AWG 28 - 12) 0.08⁄1.5 (AWG 28 - 12)
Ambient climatic conditions
Operating ambient temperature °C -25 - 55, low temperatures to IEC 60068-2-1, high temperatures to IEC 60068-2-2
Condensation Prevent condensation by means of suitable measures
LCD display (clearly legible) °C
Storage °C -40 - 70 -40 - 70 -40 - 70 -40 - 70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
% 5 - 95 5 - 95 5 - 95 5 - 95
Air pressure (in operation) hPa 795 - 1080 795 - 1080 795 - 1080 795 - 1080
Ambient mechanical conditions
Pollution degree 2 2 2 2
Protection type (IEC/EN 60529, EN50178,
VBG 4)
IP20 IP20 IP20 IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm Hz 10 - 57 10 - 57 10 - 57 10 - 57
Constant acceleration, 2 g Hz 57 - 150 57 - 150 57 - 150 57 - 150
Mechanical shock resistance
(IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18 18 18 18
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 1 1 1 1
Mounting position Vertical or horizontal
Electromagnetic compatibility (EMC)
Electrostatic discharge (ESD),
to IEC EN 61000-4-2
Air discharge kV 8 8 8 8
Contact discharge kV 6 6 6 6
Electromagnetic fields (RFI),
to IEC EN 61000-4-2
V/m 10 10 10 10
Radio interference suppression EN 55011 Class B, EN 55022 Class B
Burst to IEC/EN 61000-4-4
Supply cables kV 2 2 2 2
Signal cables kV 2 2 2 2
Power pulses (surge) (IEC/EN 61000-4-5) kV 2 (supply cables,
symmetrical)
2 (supply cables,
symmetrical)
2 (supply cables,
symmetrical)
2 (supply cables
symmetrical,
MFD-AC-CP8..)
Power pulses (surge), to IEC/EN 61000-4-5 kV 0.5 (supply cables,
symmetrical)
0.5 (supply cables,
symmetrical)
0.5 (supply cables,
symmetrical)
0.5 (supply cables,
symmetrical,
MFD-CP8..)
Radiated RFI, to IEC/EN 61000-4-6 V 10 10 10 10
Insulation resistance
Clearance in air and creepage distances EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance EN 50178
