12/38 Control relays, multi-function display
CPU, communication modules
2010 CA08103002Z-EN
MFD-(AC)-CP...
MFD-(AC)-CP...CPU,communicationmodules
MFD-CP4.. MFD-CP8..
MFD-CP10..
MFD-AC-CP4..
MFD-AC-CP8..
Power supply
Rated operational voltage Ue V 24 DC (-15⁄+20 %) 24 DC (-15⁄+20 %) 100/110/115/120//230/240 AC
(+10/-15 %)
Permissible range V AC 85…264
Permissible range V DC 20.4…28.8 20.4…28.8
Ripple % ≦ 5 ≦ 5 –
Frequency Hz – – 50⁄60 (± 5%)
Input current
At 115/120 V AC 60 Hz mA – – Normally 90
At 230/240 V AC 50 Hz mA – – Normally 60
At 24 V DC mA Normally 185 Normally 200 –
Voltage dips (IEC/EN 61131-2) ms 10 10 10
Heat dissipation
At 115/120 V AC VA – – Normally 11
At 230⁄240 V AC VA – – Normally 15
At 24 V DC W 1.5 3.4 –
Point-to-point connection
Stations 1 – –
Baud rate
easy500, easy700 MBit/s 9.6 kBaud – –
easy800, MFD, EC4P 19.2 kBaud – –
Distance m Max. 5 Max. 5 Max. 5
Potential isolation
From power supply Yes – –
From the connected device Yes – –
Terminal type Spring-loaded terminals – –
Power pulses
Stations Num-
ber
Max. 1 Max. 8 Max. 8
Data transfer rate/distance – 1000 Kbit/s, 6 m
500 Kbit/s, 25 m
250 Kbit/s, 40 m
125 Kbit/s, 125 m
50 Kbit/s, 300 m
20 Kbit/s, 700 m
10 Kbit/s, 1000 m
1000 Kbit/s, 6 m
500 Kbit/s, 25 m
250 Kbit/s, 40 m
125 Kbit/s, 125 m
50 Kbit/s, 300 m
20 Kbit/s, 700 m
10 Kbit/s, 1000 m
Potential isolation
From power supply – Yes Yes
From the inputs – – Yes
From the outputs – Yes Yes
From PC interface, memory card, easyNet,
easyLink
– Yes Yes
Bus termination (first and last station) – Yes Yes
Terminal type – RJ45, 8 pole RJ45, 8 pole
