Automation products
HMI-PLC XV400
Visualization
2010
CA08103002Z-EN
www.eaton.comVisualizationHMI-PLCXV400
XV-442-
57
CQB-1-10
XV-442-
57
CQB-1-20
XV-442-
57
CQB-1-50
XV-432-
57
CQB-1-10
XV-460-57TQB-
1-10
XV-460-57TQB-
1-50
XV-450-57TQB-
1-10
Display
Screen diagonal/type
5.7"
CSTN LCD
(
color)
5.7"
CSTN LCD
(
color)
5.7"
CSTN LCD
(
color)
5.7"
TFT LCD
(
color)
5.7"
TFT LCD
(
color)
5.7"
TFT LCD
(
color)
Resolution
QVGA (320 × 240 pixels or 240 × 320 pixels in portrait format)
Visible screen area
115
mm x
86
mm
115
mm x
86
mm
115
mm x
86
mm
115
mm x
86
mm
115
mm x
86
mm
115
mm x
86
mm
Color resolution (grayscale or color)
256
colors
256
colors
256
colors
Adjustable:
65536
or
256
colors
Adjustable:
65536
or
256
colors
Adjustable:
65536
or
256
colors
Contrast ratio
Normally 35:1 Normally 35:1 Normally 35:1 Normally 400:1 Normally 400:1 Normally 400:1
Brightness
Normally
150
cd/m²
Normally
150
cd/m²
Normally
150
cd/m²
Normally
350
cd/m²
Normally
350
cd/m²
Normally
350
cd/m²
Backlight
1
x CCFL,
dimmable via
software
1
x CCFL,
dimmable via
software
1
x CCFL,
dimmable via
software
LED, dimmable
via software
LED, dimmable
via software
LED, dimmable
via software
Lifespan of backlight
Normally
50000
h
Normally
50000
h
Normally
50000
h
Normally
40000
h
Normally
40000
h
Normally
40000
h
Resistive touch protective screen
–
–
Touch sensor
(
glass with
membrane)
–
–
Touch sensor
(
glass with
membrane)
Infra-red touch protective screen
Laminated
safety glass,
non-reflecting
Laminated
safety glass,
non-reflecting
–
Laminated
safety glass,
non-reflecting
Laminated
safety glass,
non-reflecting
–
Operation
Technology
Infra-red
touch,
47
x 31 logic
channels
Infra-red
touch,
47
x 31 logic
channels
Resistive
touch,
4-
conductor
Infra-red
touch,
47
x 31 logic
channels
Infra-red
touch,
47
x 31 logic
channels
Resistive
touch,
4-
conductor
System
Processor
RISC, 32 bit, 400 MHz
Internal memory
DRAM
(
OS, program and data memory)
64
MByte
FLASH (can be used for data backup) Approx. 1.5 MByte available
NVRAM (Retain data)
Approx. 32 kByte available
External memory
CF slot
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
1
× Compact
Flash card, type
I/IIforoperating
system,
programs and
data
Real-time clock (battery backup)
Battery
Zero
maintenance
Zero
maintenance
Zero
maintenance
Zero
maintenance
Zero
maintenance
Zero
maintenance
Backup time at zero voltage
Normally 10 years
Operating system
Windows CE Windows CE Windows CE Windows CE Windows CE Windows CE
Engineering
Visualization software
GALILEO/EPAM
PLC programming software
XSOFT-CODESYS-2
Interfaces, communication
Ethernet
100
Base-TX/10Base-T
System port
RS232, not isolated (D-sub 9-pin, UNC)
CAN
CAN, galvanically isolated (D-sub 9-pin, UNC)
PROFIBUS
–
–
–
–
–
–
USB Host
USB 2.0 (1.5/12 MBit/s), not isolated
USB device
USB 1.1, not isolated
Slots for communication cards
1
1
1
1
1
1
