Automation products
HMI XVH300
Visualization
2010
CA08103002Z-EN
www.eaton.comVisualizationHMIXVH300
XVH-340-57BAS-1-10
XVH-340-57CAN-1-10
XVH-340-57MPI-1-10
Display
Screen diagonal/type
5.7"
CSTN LCD (color)
5.7"
CSTN LCD (color)
5.7"
CSTN LCD (color)
Resolution
QVGA (320 × 240 pixels or 240 × 320 pixels in portrait format)
Visible screen area
115
mm x 86 mm
115
mm x 86 mm
115
mm x 86 mm
Color resolution (grayscale or color)
256
colors
256
colors
256
colors
Contrast ratio
Normally 35:1
Normally 35:1
Normally 35:1
Brightness
Normally 150 cd/m²
Normally 150 cd/m²
Normally 150 cd/m²
Backlight
1
x CCFL, dimmable via software
Lifespan of backlight
Normally 50000 h
Normally 50000 h
Normally 50000 h
Resistive touch protective screen
–
–
–
Infra-red touch protective screen
Laminated safety glass, non-reflective
Operation
Technology
Infra-red touch, 47 × 31 logic channels
System
Processor
RISC, 32-bit, 200 MHz
RISC, 32-bit, 200 MHz
RISC, 32-bit, 200 MHz
Internal memory
DRAM (OS, program and data memory)
64
MByte
64
MByte
64
MByte
FLASH (can be used for data backup)
Approx. 1.5 MByte available
Approx. 1.5 MByte available
Approx. 1.5 MByte available
NVRAM (Retain data)
–
–
–
External memory
CF slot
1
x CompactFlash card type I/II for operating system, programs and data
Real-time clock (battery backup)
Battery
Zero maintenance
Zero maintenance
Zero maintenance
Backup time at zero voltage
Normally 10 years
Normally 10 years
Normally 10 years
Operating system
Windows CE
Windows CE
Windows CE
Engineering
Visualization software
GALILEO/EPAM
GALILEO/EPAM
GALILEO/EPAM
PLC programming software
–
–
–
Interfaces, communication
Ethernet
100
Base-TX/10Base-T
100
Base-TX/10Base-T
100
Base-TX/10Base-T
System port
–
–
–
Com Port
–
–
–
CAN
–
CAN, isolated
(
Sub-D 9-pin plug)
–
PROFIBUS
–
–
PROFIBUS galvanically isolated,
max. 1.5 MBit/s (D-sub 9-pin
socket, UNC)
USB device
USB 1.1, not isolated
Power supply
Nominal voltage
24
V DC SELV (safety extra low voltage)
Permissible voltage
R.m.s.: 20.4 – 28.8 V DC (rated operating voltage -15 %/+20 %)
Absolute with ripple: 19.2 – 30.0 V DC
35
V DC for a duration < 100 ms
Voltage dips
20
ms from nominal voltage (24 V DC), 2 ms from undervoltage (20.4 V DC)
Input power
Max. 16 W (normally 12 W)
Max. 16 W (normally 12 W)
Max. 16 W (normally 12 W)
Protection against polarity reversal
Yes
Yes
Yes
Fuse
Yes (fuse not accessible)
Potential isolation
No (0V connection to housing potential)
