Automation products
HMI(-PLC)
Visualization
XV-102B...-35TQR-10 XV-102-B...-35TQR-10-PLC XV-102-D...-57TVR-10 XV-102-D...70TWR-10...
3.5" TFT LCD (color) 3.5" TFT LCD (color) 5.7" TFT LCD (color) 7" TFT LCD (color)
QVGA (320 × 240 pixels or 240 × 320
pixels in portrait format)
QVGA (320 × 240 pixels or 240 × 320
pixels in portrait format)
VGA (640 × 480 pixels or 480 × 640 pixels in
portrait format)
WVGA (800 × 480 pixels or 480 × 800
pixels in portrait format)
70 mm x 53 mm 70 mm x 53 mm 115 mm x 86 mm 152 mm x 91 mm
64 k Colors 64 k Colors 64 k Colors 64 k Colors
Normally 300:1 Normally 300:1 Normally 300:1 Normally 300:1
Normally 250 cd/m² Normally 250 cd/m² Normally 250 cd/m² Normally 250 cd/m²
LED, dimmable via software LED, dimmable via software LED, dimmable via software LED, dimmable via software
Normally 40000 h Normally 40000 h Normally 40000 h Normally 40000 h
Touch sensor (glass with membrane) Touch sensor (glass with membrane) Touch sensor (glass with membrane) Touch sensor (glass with membrane)
Resistive touch, 4-conductor Resistive touch, 4-conductor Resistive touch, 4-conductor Resistive touch, 4-conductor
RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz
64 MByte 64 MByte 64 MByte 64 MByte
Approx. 128 Byte available Approx. 128 Byte available Approx. 128 Byte available Approx. 128 Byte available
Approx. 32 kByte available Approx. 32 kByte available Approx. 32 kByte available Approx. 32 kByte available
SDA Specification 1.00 SDA Specification 1.00 SDA Specification 1.00 SDA Specification 1.00
Zero maintenance Zero maintenance Zero maintenance Zero maintenance
Normally 10 years Normally 10 years Normally 10 years Normally 10 years
Windows CE Windows CE Windows CE Windows CE
GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM
XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2
100Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T 100 Base-TX/10Base-T
– – USB 2.0 (1.5 - 12 Mbit/s), not isolated
USB 2.0, not isolated USB 2.0, not isolated USB 2.0, not isolated USB 2.0, not isolated
...B0… ...B2… ...B3… ...B4… ...B5… ...B0
…
...B3
…
...B4
…
...B5
…
... B6
…
...B8
…
...D0… ...D6… ...D8… ...D6...
PLC
...D8...
PLC
...D0… ...D6… ...D8… ...D6...
PLC
...D8...
PLC
– – ●1) – ●1) – ●1) – ●1) – – ●1) ●1) ●1) ●1) ●1) ●1) ●1) ●1) ●1) ●1)
– – – – ●2) – – – ●2) ●2) – – ●2) – ●2) – – ●2) – ●2) –
– ●3) – – – – – – – – ●3) – – ●3) – ●3) – – ●3) – ●3)
– – – ●4) – – – ●4) – ●4) ●4) – ●4) ●4) ●4) ●4) – ●4) ●4) ●4) ●4)
24 V DC SELV (safety extra low voltage) 24 V DC SELV (safety extra low voltage) 24 V DC SELV (safety extra low voltage) 24 V DC SELV (safety extra low voltage)
R.m.s.: 19.2 – 30.0 V DC (rated operating voltage -20 %/+25 %)
Absolute with ripple: 18.0 – 31.2 V DC
Battery operation: 18.0 – 31.2 V DC (rated operating voltage -25 %/+30 %)
35 V DC for a duration of < 100 ms
10 ms from nominal voltage (24 V DC), 5 ms from undervoltage (20.4 V DC)
Max. 5 W Max. 5 W Max. 10 W Max. 10 W
Yes Yes Yes Yes
Yes (fuse not accessible)
No No No No
Standard membrane (fully enclosed) Standard membrane (fully enclosed) Standard membrane (fully enclosed) Standard membrane (fully enclosed)
IP65 IP65 IP65 IP65
IP20 IP20 IP20 IP20
cUL cUL cUL cUL
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
EN 61000-6-2, EN 61000-6-4, EN 61131-2 EN 61000-6-2, EN 61000-6-4, EN 61131-2 EN 61000-6-2, EN 61000-6-4, EN 61131-2 EN 61000-6-2, EN 61000-6-4, EN 61131-2
EN 60079-0, EN 61241-1, EN 13463 EN 60079-0, EN 61241-1, EN 13463 EN 60079-0, EN 61241-1, EN 13463 EN 60079-0, EN 61241-1, EN 13463
EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950
EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2
Approx. 0.3 kg Approx. 0.3 kg Approx. 0.6 kg Approx. 0.6 kg
0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C
-20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C
10 - 95%, non-condensing 10 - 95%, non-condensing 10 - 95%, non-condensing 10 - 95%, non-condensing
To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27
To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6
3) PROFIBUS, not isolated, max. 1.5 MBit/s (D-sub 9-pin socket, UNC)
4) RS485, not isolated (D-sub 9-pin, UNC)
