Engineering
Protocols for communication cards for panel XV400
For panels XV400, communications protocols are available through optional plug-in communication cards (No license products required):
Excerpt From the most common protocols, which are available for XV400 devices through optional plug-in communication cards:
Protocol
Required communication cards for XV400
EIB (3rd release)
COM-EIB2-TP
Matsushita FP series
COM-MPB1-TP / COM-MPB2-TP
Mitsubishi A series/F series
COM-MPB1-TP / COM-MPB2-TP
Moeller Suconet K
COM-MPB1-TP / COM-MPB2-TP
Omron C, H, or K series
COM-MPB1-TP / COM-MPB2-TP
PROFIBUS-DP master (12 Mbaud)
COM-DPM-MC2
PROFIBUS-DP slave (12 Mbaud)
COM-PDP-TP
Siemens MPI
COM-MPB2-TP
Telemecanique Unitelway new
COM-MPB1-TP / COM-MPB2-TP
To inquire about further protocols, contact your vendor.
Licensing for Panel XV…
The panels XV100, XV200, XVH300, XV400, XVS400 and XVM400 are supplied with license points saved to the device. License points are required to be able to
perform certain functions with the device:
•
XSOFT-CODESYS-2 runtime for the PLC function (not possible with XV-102-A…,XVH300 and XVM400)
•
Runtime for the visualization (GALILEO or EPAM)
•
Tools (e. g. CE Telediag, S7 PG Router)
•
Communication (e.g. Ethernet, CANopen, Siemens MPI)
Number of license points supplied with standard devices:
• 140
license points: XV100 (without PLC function), XV200, XVH300, XV400, XVS400
• 240
license points: XV100 with PLC function
• 260
licence points: XVM400
If the device does not contain enough license points for the required functions or to add the PLC function to the HMI, you must purchase additional license points.
To do this you need one or more license product certificates. The following are available:
•
License product certificates for the PLC function: To enable the PLC function (XSOFT-CODESYS-2) special license product certificates are required. These
contain a license label for the device type, which must be applied to the device fir legal reasons.
•
License product certificates for visualization, communication and tools
Determining required license points
For the visualization and tools and communication features used, add the license points required for each function. Communication connections to several
devices with the same protocol must be counted only once. From this total, subtract the points already contained on the devices (e.g. 140 points).
The difference is the number of license points that you must install for communication protocols and tools through license product certificates.
Table: Required license points for runtime and tools
Visualization/Tools
Required on-board interface
Licence points
GALILEO-Runtime
None
100
EPAM runtime
None
100
XSOFT-CODESYS-2 runtime
(
PLC function)
None
100
XSOFT-CODESYS-2 runtime (PLC
function and TargetVisu function)
None
200
CE Telediag
RS232
40
S7 PG Router
Ethernet and PROFIBUS
80
CAN Monitor
CAN
0
Domain Server
Ethernet
80
