127 / 253
Automation products
HMI-PLC XV400
2010
CA08103002Z-EN
www.eaton.comVisualization
14/11
XV400
–
Display: 10.4", 12.1" or 15" TFT LCD (Color display), adjustable: 65536 or 256 colors
–
2
slots for Compact Flash™ cards
–
2
slots for communication cards
–
Built-in interfaces: 1 × Ethernet 100/10, 1 × RS232, 1 × CAN, 2 × USB host, 1 × USB device
Infra-red touch
10.4"
TFT LCD
Standard front with
standard membrane
Laminated safety glass,
non-reflective
10.4
640
x 480
XV-440-10TVB-1-10
139904
1
off
–
Infra-red touch
10.4"
TFT LCD
Four-hole front with
standard membrane
Laminated safety glass,
non-reflective
10.4
640
x 480
XV-440-10TVB-1-20
139906
1
off
1)
Infra-red touch
10.4"
TFT LCD
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
10.4
640
x 480
XV-440-10TVB-1-50
139908
1
off
2)
Resistive touch
10.4"
TFT LCD
Standard front with
standard membrane (fully
laminated)
10.4
640
x 480
XV-430-10TVB-1-10
139902
1
off
–
Infra-red touch
12.1"
TFT LCD
Standard front with
standard membrane
Laminated safety glass,
non-reflective
12.1
800
x 600
XV-440-12TSB-1-10
139911
1
off
–
Infra-red touch
12.1"
TFT LCD
Four-hole front with
standard membrane
Laminated safety glass,
non-reflective
12.1
800
x 600
XV-440-12TSB-1-20
139913
1
off
1)
Infra-red touch
12.1"
TFT LCD
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
12.1
800
x 600
XV-440-12TSB-1-50
139915
1
off
2)
Resistive touch
12.1"
TFT LCD
Standard front with
standard membrane (fully
laminated)
12.1
800
x 600
XV-430-12TSB-1-10
139909
1
off
–
Infra-red touch
15"
TFT LCD
Standard front with
standard membrane
Laminated safety glass,
non-reflective
15
1024
x 768
XV-460-15TXB-1-10
139916
1
off
–
Infra-red touch
15"
TFT LCD
Four-hole front with
standard membrane
Laminated safety glass,
non-reflective
15
1024
x 768
XV-460-15TXB-1-20
139917
1
off
1)
Infra-red touch
15"
TFT LCD
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
15
1024
x 768
XV-460-15TXB-1-50
139918
1
off
–
Instructions
1)
Not for new applications.
2)
Approved for II 2G Ex px II IP5x (ATEX 94/9/EC):
Zone 1, Category 2G (Only for flush-mounting in a pressurized enclosure!
Max. permissible excess pressure: 10 mbar continuous.)
Zone 2, Category 3G (Only for flush-mounting in a pressurized enclosure!
Max. permissible excess pressure: 10 mbar continuous.)
Information relevant for export to North America
Product Standards
UL 60950-01; cUL; IEC/EN 61131-2; CE marking
UL File No.
E208621
UL CCN
NWGQ2, NWGQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Conditions of Acceptability
The investigated Pollution Degree is: 2
Proper bonding to the end-product main protective earthing
termination is: Required
The following end-product enclosures are required: Fire, Electrical
The unit must be supplied via a SELV source.
The provided Ethernet Connection is only allowed to connect to
inhouse networks.
Degree of Protection
IEC: IP65, UL/CSA Type: -
Display
Front design
Screen
diagonal
Resolution
Part No.
Article No.
Price
See price
list
Std. pack
Notes
Inches
Pixels
HPL14011EN
