123 / 253
Automation products
HMI-PLC MFD4, HMI XVH300
2010
CA08103002Z-EN
www.eaton.comVisualization
14/7
VisualizationHMI-PLCMFD4,HMIXVH300Visualization
Visualization
Display
Screen
diagonal
Resolution Communication
interface
Part No.
Article No.
Price
See price
list
Std. pack
Inches
Pixels
MFD4
•
Memory card pluggable (optional) ￫Page 14/41
•
Real-time clock
•
Operating system: Windows CE
Resistive touch
5.7"
TFT LCD
32
k Colors
5.7
320
x 240 Ethernet
CANopen/easyNet
RS232
MFD4-5-XRC-30
109428
1
off
XVH300
•
HMI (No PLC function possible) with communication through on-board interface.
•
Communication scope extendable through licensing, ￫Page 14/12.
•
Standard front, special front please inquire
•
Metal enclosure and front plate
•
Processor: RISC central processing unit, 32-bit, 200 MHz
•
OS, program and data memory: 64 MB
•
Display: 5.7" CSTN LCD (Color display), 256 colors
•
Built-in interfaces: 1 × Ethernet, 1 × USB device, communications interface
• 1
slot for 1 Compact Flash™ card
•
Software (engineering): visualization = GALILEO or EPAM
•
WinCE license required￫XV accessories
•
Compact Flash™ required ￫XV accessories
Infra-red touch
5.7"
CSTN LCD
(
Color display)
Standard front with
standard membrane
Laminated safety glass,
non-reflective
5.7
320
x 240 –
XVH-340-57BAS-1-10
139869
1
off
5.7
320
x 240 CAN
XVH-340-57CAN-1-10
139870
5.7
320
x 240 PROFIBUS
XVH-340-57MPI-1-10
139871
5.7
320
x 240 RS485 (Suconet K)
RS232 (Sucom A)
XVH-342-57SKS-1-10
139873
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
5.7
320
x 240 CAN
XVH-340-57CAN-1-50
1)
139872
Resistive touch
5.7"
CSTN LCD
(
Color display)
Standard front with
standardmembrane(fully
laminated)
5.7
320
x 240 –
XVH-330-57BAS-1-10
139866
5.7
320
x 240 CAN
XVH-330-57CAN-1-10
139867
5.7
320
x 240 PROFIBUS
XVH-330-57MPI-1-10
139868
Notes
1)
Approved for IP69K.
Observe installation instructions to IP69K.
Information relevant for export to North America
Product Standards
UL 60950-01; cUL; IEC/EN 61131-2;
CE marking
UL File No.
E208621
UL CCN
NWGQ2, NWGQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Conditions of Acceptability The investigated Pollution Degree is: 2
Proper bonding to the end-product main protective earthing
termination is: Required
The following end-product enclosures are required: Fire,
Electrical
The unit must be supplied via a SELV source.
The provided Ethernet Connection is only allowed to connect
to inhouse networks.
Degree of Protection
IEC: IP65, UL/CSA Type: -
HPL14007EN
