Automation products
HMI(-PLC) XV100
2010 CA08103002Z-EN
Visualization 14/5
VisualizationHMI(-PLC)XV100Ordering
Display Front design Screen
diagonal
Resolution Communication
interface
Part No.
Article No.
Price
See
price list
Std. pack
Inches Pixels
XV100
• HMI or HMI PLC with communication through on-board interface.
• Communication scope extendable through licensing, ￫Page 14/12.
• Standard front, special front please inquire
• Insulating enclosure and front plate
• Processor: RISC central processing unit, 32-bit, 400 MHz
• OS, program and data memory: 64 MB
• 1 slot for 1 SD card
• Software (engineering): Visualization = GALILEO or EPAM, PLC = XSOFT-CODESYS-2
(depending on version)
• Windows CE Core 5.0 license (incl.)
– Built-in interfaces: 1 × Ethernet 100/10, 1 × USB device, communications interface
– No PLC function possible
Resistive touch
3.5''TFT LCD
32 grey levels
Standard
membrane
(fully
enclosed)
3.5 320 x 240 – XV-102-A0-35MQR-10
141759
1 off
3.5 320 x 240 PROFIBUS XV-102-A2-35MQR-10
141820
3.5 320 x 240 RS232 XV-102-A3-35MQR-10
141821
3.5 320 x 240 RS485 XV-102-A4-35MQR-10
141822
3.5 320 x 240 CAN
RS232
XV-102-A5-35MQR-10
141823
– Built-in interfaces: 1 × Ethernet 100/10, 1 × USB device, communications interface
– Can be expanded with PLC function, ￫Page 14/14
Resistive touch
3.5''TFT LCD
64 k Colors
Standard
membrane
(fully
enclosed)
3.5 320 x 240 – XV-102-B0-35TQR-10
140007
1 off
3.5 320 x 240 PROFIBUS XV-102-B2-35TQR-10
140008
3.5 320 x 240 RS232 XV-102-B3-35TQR-10
140009
3.5 320 x 240 RS485 XV-102-B4-35TQR-10
140010
3.5 320 x 240 CAN
RS232
XV-102-B5-35TQR-10
140011
– Including PLC function
– Built-in interfaces: 1 × Ethernet 100/10, 1 × USB device, communications interface
Resistive touch
3.5''TFT LCD
32 grey levels
Standard
membrane
(fully
enclosed)
3.5 320 x 240 – XV-102-B0-35MQR-10-PLC
140012
1 off
3.5 320 x 240 RS232 XV-102-B3-35MQR-10-PLC
140013
3.5 320 x 240 RS485 XV-102-B4-35MQR-10-PLC
140014
3.5 320 x 240 CAN
RS232
XV-102-B5-35MQR-10-PLC
140015
3.5 320 x 240 CAN
RS485
XV-102-B6-35MQR-10-PLC
140016
3.5 320 x 240 PROFIBUS
RS485
XV-102-B8-35MQR-10-PLC
140017
Resistive touch
3.5''TFT LCD
64 k Colors
3.5 320 x 240 – XV-102-B0-35TQR-10-PLC
140018
3.5 320 x 240 RS232 XV-102-B3-35TQR-10-PLC
140019
3.5 320 x 240 RS485 XV-102-B4-35TQR-10-PLC
140020
3.5 320 x 240 CAN
RS232
XV-102-B5-35TQR-10-PLC
140021
3.5 320 x 240 CAN
RS485
XV-102-B6-35TQR-10-PLC
140022
3.5 320 x 240 PROFIBUS
RS485
XV-102-B8-35TQR-10-PLC
140023
Information relevant
for export to
North America
Product Standards UL 60950-01; cUL;
IEC/EN 61131-2; CE marking
UL File No. E208621
UL CCN NWGQ2, NWGQ8
CSA File No. UL report applies to both US and Canada
CSA Class No. -
NA Certification UL Recognized, certified by UL for use in Canada
Conditions of Acceptability
The investigated Pollution Degree is: 2
The following end-product enclosures are required:
Fire. The unit must be supplied via a SELV source. The
provided Ethernet Connection is only allowed to
connect to inhouse networks
Degree of Protection
IEC: IP65, UL/CSA Type: -
