14/10 Automation products
HMI-PLC XV400
2010 CA08103002Z-EN
Visualization
VisualizationHMI-PLCXV400
Display Front design Screen
diagonal
Resolution Part No.
Article No.
Price
See price
list
Std. pack Notes
Inches Pixels
XV400
• HMI or HMI PLC with communication through on-board interface.
• PLC function and communications scope can be upgraded with licenses, ￫Page 14/12.
• Standard front, stainless steel front, special fronts please inquire
• Metal enclosure and front plate
• Processor: RISC central processing unit, 32-bit, 400 MHz
• OS, program and data memory: 64 MB
• Software (engineering): visualization = GALILEO or EPAM, PLC = XSOFT-CODESYS-2
• WinCE license required￫XV accessories
• Compact Flash™ required ￫S XV accessories
– Display: 5.7" CSTN LCD (color display), 256 colors
– 1 slot for Compact Flash™ cards
– 1 slot for communication cards
– Built-in interfaces: 1 × Ethernet 100/10, 1 × RS232, 1 × CAN, 1 × USB host, 1 × USB device
Infra-red touch
5.7" CSTN LCD
(Color display)
Standard front with
standard membrane
Laminated safety glass,
non-reflective
5.7 320 x 240 XV-442-57CQB-1-10
139892
1 off –
Infra-red touch
5.7" CSTN LCD
(Color display)
Four-hole front with
standard membrane
Laminated safety glass,
non-reflective
5.7 320 x 240 XV-442-57CQB-1-20
139894
1)
Infra-red touch
5.7" CSTN LCD
(Color display)
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
5.7 320 x 240 XV-442-57CQB-1-50
139896
1) 2)
Resistive touch
5.7" CSTN LCD
(Color display)
Standard front with
standard membrane (fully
laminated)
5.7 320 x 240 XV-432-57CQB-1-10
139890
–
– Display: 5.7" or 8.4" TFT LCD (Color display), adjustable: 65536 or 256 colors
– 1 slot for Compact Flash™ card
– 1 slot for communication cards
– Built-in interfaces: 1 × Ethernet 100/10, 1 × RS232, 1 × CAN, 1 × USB host, 1 × USB device
Infra-red touch
5.7" TFT LCD
Standard front with
standard membrane
Laminated safety glass,
non-reflective
5.7 320 x 240 XV-460-57TQB-1-10
139897
1 off –
Infra-red touch
5.7" TFT LCD
Satin-finish brushed
stainless steel
Laminated safety glass,
non-reflective
5.7 320 x 240 XV-460-57TQB-1-50
139898
2)
Resistive touch
5.7" TFT LCD
Standard front with
standard membrane (fully
laminated)
5.7 320 x 240 XV-450-57TQB-1-10
139899
–
Infra-red touch
8.4" TFT LCD
Standard front with
standard membrane
Laminated safety glass,
non-reflective
8.4 640 x 480 XV-460-84TVB-1-10
139900
–
Instructions 1) Not for new applications.
2) Approved for II 2G Ex px II IP5x (ATEX 94/9/EC):
Observe installation instructions to IP69K.
Information relevant for export to North America Product Standards UL 60950-01; cUL; IEC/EN 61131-2; CE marking
UL File No. E208621
UL CCN NWGQ2, NWGQ8
CSA File No. UL report applies to both US and Canada
CSA Class No. –
NA Certification UL Recognized, certified by UL for use in Canada
Conditions of Acceptability The investigated Pollution Degree is: 2
Proper bonding to the end-product main protective earthing
termination is: Required
The following end-product enclosures are required: Fire, Electrical
The unit must be supplied via a SELV source.
The provided Ethernet Connection is only allowed to connect to
inhouse networks.
Degree of Protection IEC: IP65, UL/CSA Type: -
