Visualization
Communication cards for MICRO PANEL XV400
For panels XV400 further communications protocols are available through optional plug-in communication cards (No license products required).
Depending on the required functionality the following license product certificates are available (
￫
XV accessories):
Licensing examples
Table: Required license points for communication through on-board interface
Manufacturer
PLC
Protocol
Required
on-board
interface
Licencepoints
XSOFT-CODE-
SYS-2
Licence points
GALILEO
Licence points EPAM
Eaton
XV with PLC function
Local
-
0
0
XV with PLC function
Ethernet
0
40
0
CANopen, master
CAN
0
-
-
CANopen, PDO
CAN
0
40
-
CANopen, SDO
CAN
0
40
-
XV200 DP master
(1.5
MBaud)
PROFIBUS
40
-
-
XV100/XVS400 DP master
(1.5
Mbaud)
PROFIBUS
0
-
-
Modbus RTU
RS232
0
40
-
Modbus TCP
Ethernet
0
80
-
CoDeSys
Ethernet
0
40
0
A. Bradley
Logix
DF1
RS232
-
120
-
Logix
Ethernet/IP
Ethernet
-
120
-
MicroLogix
SLC5/03 MicroLogix DF1
RS232
-
40
-
Beckhoff
TwinCAT
ADS
Ethernet
-
80
-
BC9000
ADS
Ethernet
-
80
-
HIMA
HIMatrix
Modbus TCP
Ethernet
-
80
-
Mitsubishi
PG-AX/PG-FX
RS232
-
40
-
Eaton
easy500/easy700
RS232
-
40
-
easy800/MFD-Titan
RS232
-
40
-
PS4
RS232
-
40
-
XC100, XC200
CAN
-
40
-
XC100, XC200
Ethernet
-
40
-
PS4
Suconet K
(
to XVH342-57SKS)
Suconet K
-
0
-
Siemens
S7
Industrial Ethernet
Ethernet
-
80
-
S7
MPI
PROFIBUS
-
40
-
S7
PROFIBUS-DP (1.5 Mbaud)
S7 default profile
PROFIBUS
-
40
-
S7-200
PPI
PROFIBUS
-
40
-
-
-
XVM400 keypad
Local
-
40
-
-
Communication currently not available
To inquire about further protocols, contact your vendor.
HMI application: XV100, XV200, XVS400
Visualization, communication
Visualization (GALILEO)
100
Points
Communication MPI
40
Points
Communication CoDeSys external
40
Points
Total
180
Points
Contained in device on delivery
-140
Points
Additionally required points for
communication
40
Points
PLC
PLC application
No
Required license product certificates:
1
x LIC-OPT-1ST-LEVEL (40 points)
Ethernet
CoDeSys
HMI
MPI
