14/18 Automation products
HMI(-PLC)
Visualization
2010 CA08103002Z-EN
VisualizationHMI(-PLC)
XV-102-A...-35MQR-10 XV-102-B...-35MQR-10-PLC
Technical data
Display
Screen diagonal/type 3.5" TFT LCD (monochrome) 3.5" TFT LCD (monochrome)
Resolution QVGA (320 × 240 pixels or 240 × 320 pixels in portrait
format)
QVGA (320 × 240 pixels or 240 × 320 pixels in portrait
format)
Visible screen area 70 mm x 53 mm 70 mm x 53 mm
Color resolution (grayscale or color) 32 grey levels 32 grey levels
Contrast ratio Normally 300:1 Normally 300:1
Brightness Normally 250 cd/m² Normally 250 cd/m²
Backlight LED, dimmable via software LED, dimmable via software
Lifespan of backlight Normally 40000 h Normally 40000 h
Resistive touch protective screen Touch sensor (glass with membrane) Touch sensor (glass with membrane)
Operation
Technology Resistive touch, 4-conductor Resistive touch, 4-conductor
System
Processor RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz
Internal memory
DRAM (OS, program and data memory) 64 MByte 64 MByte
NAND FLASH (can be used for data backup) Approx. 128 Byte available Approx. 128 Byte available
NVRAM (Retain data) – Approx. 32 kByte available
External memory
SD Memory Card Slot SDA Specification 1.00 SDA Specification 1.00
Real-time clock (battery backup)
Battery Zero maintenance Zero maintenance
Backup time at zero voltage Normally 10 years Normally 10 years
Operating system Windows CE Windows CE
Engineering
Visualization software GALILEO/EPAM GALILEO/EPAM
PLC programming software – XSOFT-CODESYS-2
Interfaces, communication
Ethernet 100Base-TX/10Base-T 100Base-TX/10Base-T
USB Host – –
USB device USB 2.0, not isolated USB 2.0, not isolated
Part No. ...A0… ...A2… ...A3… ...A4… ...A5… ...B0… ...B3… ...B4… ...B5… ...B6… ...B8…
System Port (RS232) – – ●1) – ●1) – ●1) – ●1) – –
CAN – – – – ●2) – – – ●2) ●2) –
PROFIBUS – ●3) – – – – – – – – ●3)
RS485 – – – ●4) – – – ●4) – ●4) ●4)
Power supply
Nominal voltage 24 V DC SELV (safety extra low voltage) 24 V DC SELV (safety extra low voltage)
Permissible voltage R.m.s.: 19.2 – 30.0 V DC (rated operating voltage -20 %/+25 %)
Absolute with ripple: 18.0 – 31.2 V DC
Battery operation: 18.0 – 31.2 V DC (rated operating voltage -25 %/+30 %)
35 V DC for a duration of < 100 ms
Voltage dips 10 ms from nominal voltage (24 V DC), 5 ms from undervoltage (20.4 V DC)
Input power Max. 5 W Max. 5 W
Protection against polarity reversal Yes Yes
Fuse Yes (fuse not accessible) Yes (fuse not accessible)
Potential isolation No No
General
Front design Standard membrane (fully enclosed) Standard membrane (fully enclosed)
Degree of protection
Front IP65 IP65
Rear IP20 IP20
Approvals
Approvals cUL cUL
Explosion protection (According to ATEX 94/9/EC) II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
Applied standards and directives
EMC (relevant for CE) EN 61000-6-2, EN 61000-6-4, EN 61131-2 EN 61000-6-2, EN 61000-6-4, EN 61131-2
Explosion protection (relevant for CE) EN 60079-0, EN 61241-1, EN 13463 EN 60079-0, EN 61241-1, EN 13463
Safety EN 60950/UL 60950 EN 60950/UL 60950
Product standards EN 50178, EN 61131-2 EN 50178, EN 61131-2
Weight Approx. 0.3 kg Approx. 0.3 kg
Environmental Conditions
Temperature
Operation 0 – 50°C 0 – 50°C
Storage/transport -20 – 60°C -20 – 60°C
Relative humidity 10 - 95%, non-condensing 10 - 95%, non-condensing
Impact resistance To IEC 68-2-27 To IEC 68-2-27
Vibration To IEC 68-2-6 To IEC 68-2-6
Notes 1) RS232, not isolated (D-sub 9-pin, UNC)
2) CAN, not isolated (D-sub 9-pin, UNC)
