HMI-PLC XV200
2010 CA08103002Z-EN
Visualization
VisualizationHMI-PLCXV200
XV-230-57CNN-1-10 XV-230-57MPN-1-10 XV-232-57BAS-1-10 XV-252-57CNN-1-10 XV-252-57MPN-1-10
Display
Screen diagonal/type 5.7" FSTN LCD (monochrome display) 5.7" CSTN LCD (Color display)
Resolution QVGA (320 × 240 pixels or 240 × 320 pixels in portrait format)
Visible screen area 115 mm x 86 mm
Color resolution (grayscale or color) 256 grey levels 256 grey levels 256 grey levels 256 colors 256 colors
Contrast ratio Normally 10:1 Normally 10:1 Normally 10:1 Normally 35:1 Normally 35:1
Brightness Normally 150 cd/m²
Backlight 1 x CCFL, dimmable via software
Lifespan of backlight Normally 50000 h
Resistive touch protective screen Touch sensor (glass with membrane)
Operation
Technology Resistive touch, 4-conductor
System
Processor RISC, 32-bit, 200 MHz
Internal memory
DRAM (OS, program and data
memory)
32 MByte 32 MByte 32 MByte 32 MByte 32 MByte
FLASH (can be used for data
backup)
Approx. 1.5 MByte available
NVRAM (Retain data) Approx. 100 Byte available
External memory
CF slot 1 x CompactFlash card type I for operating system, programs and data
Real-time clock (battery backup)
Battery Zero maintenance Zero maintenance Zero maintenance Zero maintenance Zero maintenance
Backup time at zero voltage Normally 10 years Normally 10 years Normally 10 years Normally 10 years Normally 10 years
Operating system Windows CE Windows CE Windows CE Windows CE Windows CE
Engineering
Visualization software GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM
PLC programming software XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2
Interfaces, communication
Ethernet 100Base-TX/10Base-T
System port – – RS232, not isolated (D-sub 9-pin, UNC)
CAN CAN, not isolated
(D-sub 9-pin, UNC)
– – CAN, not isolated
(D-sub 9-pin, UNC)
–
PROFIBUS – PROFIBUS,
not isolated,
max. 1.5 MBit/s
(D-sub 9-pin socket,
UNC)
– – PROFIBUS,
not isolated,
max. 1.5 MBit/s
(D-sub 9-pin, UNC)
USB device USB 1.1, not isolated
Power supply
Nominal voltage 24 V DC SELV (safety extra low voltage)
Permissible voltage R.m.s.: 19.2 – 30.0 V DC (rated operating voltage -20 %/+25 %)
Absolute with ripple: 18.0 – 31.2 V DC
Battery operation: 18.0 – 31.2 V DC (rated operating voltage -25 %/+30 %)
35 V DC for a duration of < 100 ms
Voltage dips 20 ms from nominal voltage (24 V DC), 10 ms from undervoltage (20.4 V DC)
Input power Max. 8 W Max. 8 W Max. 8 W Max. 8 W Max. 8 W
Protection against polarity reversal Yes Yes Yes Yes Yes
Fuse Yes (zero
maintenance)
Yes (zero
maintenance)
Yes (zero
maintenance)
Yes (zero
maintenance)
Yes (zero
maintenance)
Potential isolation No No No No No
