Automation products
HMI XVH300
Visualization
XVH-342-57SKS-1-10 XVH-340-57CAN-1-50 XVH-330-57BAS-1-10 XVH-330-57CAN-1-10 XVH-330-57MPI-1-10
5.7" CSTN LCD (color) 5.7" CSTN LCD (color) 5.7" CSTN LCD (color) 5.7" CSTN LCD (color) 5.7" CSTN LCD (color)
QVGA (320 × 240 pixels or 240 × 320 pixels in portrait format)
115 mm x 86 mm 115 mm x 86 mm 115 mm x 86 mm 115 mm x 86 mm 115 mm x 86 mm
256 colors 256 colors 256 colors 256 colors 256 colors
Normally 35:1 Normally 35:1 Normally 35:1 Normally 35:1 Normally 35:1
Normally 150 cd/m² Normally 150 cd/m² Normally 150 cd/m² Normally 150 cd/m² Normally 150 cd/m²
1 x CCFL, dimmable via software
Normally 50000 h Normally 50000 h Normally 50000 h Normally 50000 h Normally 50000 h
– – Touch sensor
(glass with membrane)
Touch sensor
(glass with membrane)
Touch sensor
(glass with membrane)
Laminated safety glass, non-reflective – – –
Infra-red touch, 47 × 31 logic channels Resistive touch, 4-conductor Resistive touch, 4-conductor Resistive touch, 4-conductor
RISC, 32-bit, 200 MHz RISC, 32-bit, 200 MHz RISC, 32-bit, 200 MHz RISC, 32-bit, 200 MHz RISC, 32-bit, 200 MHz
64 MByte 64 MByte 64 MByte 64 MByte 64 MByte
Approx. 1.5 MByte available Approx. 1.5 MByte available Approx. 1.5 MByte available Approx. 1.5 MByte available Approx. 1.5 MByte available
– – – – –
1 x CompactFlash card type I/II for operating system, programs and data
Zero maintenance Zero maintenance Zero maintenance Zero maintenance Zero maintenance
Normally 10 years Normally 10 years Normally 10 years Normally 10 years Normally 10 years
Windows CE Windows CE Windows CE Windows CE Windows CE
GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM
– – – – –
100 Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T
RS232 (SucomA), not isolated
(Sub-D 9.pin plug, UNC)
– – – –
RS485 (Suconet K), isolated
(Sub-D 9-pin socket, UNC)
– – – –
– CAN, galvanically isolated
(D-sub 9-pin, UNC)
– CAN, galvanically isolated
(D-sub 9-pin, UNC)
–
– – – – PROFIBUS galvanically
isolated, max. 1.5 MBit/s
(D-sub 9-pin socket, UNC)
USB 1.1, not isolated
24 V DC SELV (safety extra low voltage)
R.m.s.: 20.4 – 28.8 V DC (rated operating voltage -15 %/+20 %)
Absolute with ripple: 19.2 – 30.0 V DC
35 V DC for a duration < 100 ms
20 ms from nominal voltage (24 V DC), 2 ms from undervoltage (20.4 V DC)
Max. 21 W (normally 17 W) Max. 16 W (normally 12 W) Max. 16 W (normally 12 W) Max. 16 W (normally 12 W) Max. 16 W (normally 12 W)
Yes Yes Yes Yes Yes
Yes (fuse not accessible)
No (0V connection to housing potential)
