Automation products
HMI XVH300
Visualization
Standard front with standard
membrane
Satin-finish brushed stainless
steel
Standard front with standard
membrane (fully laminated)
Standard front with standard
membrane (fully laminated)
Standard front with standard
membrane (fully laminated)
IP65 IP65, IP69K IP65 IP65 IP65
Additional mounting
bracket set required for flush
mounting (￫Accessories)
Observe installation
instructions to IP69K
Additional mounting
bracket set required for flush
mounting (￫Accessories)
Additional mounting
bracket set required for flush
mounting (￫Accessories)
Additional mounting
bracket set required for flush
mounting (￫Accessories)
IP20 IP20 IP20 IP20 IP20
cUL cUL cUL cUL cUL
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
Additional mounting bracket
set required for flush
mounting (￫Accessories)
Additional mounting bracket
set required for flush
mounting (￫Accessories)
Additional mounting bracket
set required for flush
mounting (￫Accessories)
Additional mounting bracket
set required for flush
mounting (￫Accessories)
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950
EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2
Approx. 1.9 kg Approx. 2.1 kg Approx. 1.7 kg Approx. 1.7 kg Approx. 1.7 kg
0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C
-20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C
10 - 95%, non-condensing
To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27
To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6
XVH-342-57SKS-1-10 XVH-340-57CAN-1-50 XVH-330-57BAS-1-10 XVH-330-57CAN-1-10 XVH-330-57MPI-1-10
